TURBO HD 5 MP
Bullet & Turret Camera

User Manual

UD03909N
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
0100001061208

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION TURBO HD 5 MP

Summary of Contents for HIKVISION TURBO HD 5 MP

  • Page 1: User Manual

    TURBO HD 5 MP Bullet & Turret Camera User Manual UD03909N User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual may contain technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.

  • Page 4: Product Features

     Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time.  The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.

  • Page 5: Installation

    1.2.2 Overview of Type II Camera 12 VDC Camera Enclosure Power Cord Mounting Base Video Cable Clip Plate Figure 1-2 Overview of Type II Camera 2 Installation Before you start:  Make sure that the device in the package is in good condition and all the assembly parts are included.

  • Page 6: Ceiling/Wall Mounting With Junction Box

    Figure 2-2 Fix the Camera to the Ceiling Note: In the supplied screw package, both self-tapping  screws, and expansion blots are contained. If the ceiling/wall is cement, expansion blots are  required to fix the camera. If the ceiling/wall is wooden, self-tapping screws are required.
  • Page 7 Junction Box Cover Figure 2-4 Fix the Camera with the Gang Box 5. Attach the junction box’s body to the ceiling/wall by aligning the screw holes of the junction box. 6. Secure the junction box’s body with supplied screws on the ceiling/wall. Figure 2-5 Fix the Camera to the Ceiling 7.
  • Page 8 Figure 2-8 Remove the Clip Plate 4. Fix the mounting base on the ceiling with screws. Figure 2-9 Fix the Mounting Base on the Ceiling Note: In the supplied screw package, both self-tapping  screws and expansion bolts are contained. For cement ceiling/wall, expansion bolts are ...
  • Page 9 Pan Position Range [0° to 360°] Tilt Position Range [0° to 75°] Rotation Position Range [0° to 360°] Figure 2-11 3-axis Adjustment 2.2.2 Ceiling/Wall Mounting with JunctionBox Note: You need to purchase a junction box separately if you adopt the mounting with a junction box Steps: 1.

  • Page 10: Menu Description

    Figure 2-15 Fix the Gang Box 8. Repeat steps 5 to 9 of 2.2.1 Ceiling/Wall Mounting without Junction Box to complete the installation. 3 Menu Description Purpose: Call the menu by clicking button on the PTZ interface, or call preset No.95. Figure 3-1 Connection Steps: 1.

  • Page 11: Output Mode

    RESOLUTION OUTPUT FRAME RATE MODE VIDEO OUT RETURN SMART FOCUS SHUTTER FLICKER MODE BRIGHTNESS EXPOSURE D-WDR RETURN MAIN MENU BACKLIGHT WHITE AWC- SET MANUAL COLOR DAY & NIGHT B/ W AUTO MIRROR SPECIAL LANGUAGE RETURN SHARPNESS ADJUST MONITOR RETURN SAVE & END EXIT RESET NOT SAVE...

  • Page 12: Smart Focus

    3.2 SMART FOCUS You are allowed to adjust the focus by clicking FOCUS+, or FOCUS-, and adjust zoom ration by click ZOOM+, or ZOOM-. 3.3 EXPOSURE Exposure describes the brightness-related parameters. You can adjust the image brightness by the SHUTTER FLICKER MODE, AGC, BRIGHTNESS, and D-WDR in different light conditions.

  • Page 13: Day & Night

    High Light Compensation: Masks strong light sources that usually flare across a scene. This makes it possible to see the detail of the image that would normally be hidden. 3.5 WB (White Balance) White balance is the white rendition function of the camera to adjust the color temperature according to the environment.
  • Page 14 LIVE DPC, WHITE DPC and BLACK DPC are adjustable in this section. LIVE DPC: Detects and corrects the dynamic or the real-time defective pixels occur during the using. ON, and OFF are selectable. The correction level from 0 to 255 is configurable if the LIVE DPC is set as ON, set it as OFF to disable the live defective pixel correction.
