TURBO HD
H0T Series Turret Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Model
DS-2CE56H0T-IT1F
DS-2CE56H0T-IT3F
DS-2CE56H0T-ITMF
DS-2CE56H0T-ITPF
0100001071116
Advertisement
Table of Contents
Related Manuals for HIKVISION TURBO HD DS-2CE56H0T-IT1F
Summary of Contents for HIKVISION TURBO HD DS-2CE56H0T-IT1F
- Page 1 TURBO HD H0T Series Turret Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE56H0T-IT1F Type I Camera DS-2CE56H0T-IT3F Type II Camera...
- Page 2 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 4 Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage 1 Introduction 1.1 Product Features...
-
Page 5: Installation
Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. 1.2.3 Overview of Type III Camera Mounting Base Switch Button Power Cord 12 VDC DC12V Video Cable Main Body... - Page 6 4. Drill the screw holes and the cable hole (optional) on the ceiling/wall according to the drill template. Figure 2-2 Drill Template Note: Drill the cable hole, when adopting the ceiling outlet to route the cable 5. Attach the mounting base to the ceiling/wall, and secure them with supplied screws.
- Page 7 2.1.2 Mounting with Inclined Ceiling Mount Steps: 1. Paste the drill template (supplied) to the place where you want to install the camera. 2. Drill screw holes, and the cable hole on the ceiling/wall according to the supplied drill template. Screw Hole Cable Hole...
- Page 8 mounting as the reference, when adopting the wall mounting. Steps: 1. Disassemble the turret camera by rotating the camera to align the notch to the clip plate, as shown in the Figure 2-10. Clip Plate Notch Figure 2-10 Disassemble the Camera 2.
- Page 9 not, adjust the camera according to the figure below to get an optimum angle. Pan Position [0° to 360°] Tilt Position Rotation Position [0° to 75°] [0° to 360°] Figure 2-14 3-axis Adjustment 1). Hold the camera body, and rotate the enclosure to adjust the pan position [0°...
- Page 10 Steps: Drill four screw holes in the wall according to the holes of the mount. 2. Install the mount to the wall by aligning the four screw holes of the mount with expansion screws on the wall. 3. Secure the mount with four hex nuts and washers. Figure 2-17 Install the Mount 4.
-
Page 11: Menu Description
Note: Drill the cable hole, when adopting the ceiling outlet to route the cable 5. Attach the mounting base to the ceiling/wall, and secure them with supplied screws. Figure 2-21 Attach the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping ... - Page 12 Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. TVI DVR Camera Monitor Figure 3-1 Connection 2. Power on the analog camera, TVI DVR, and the monitor to view the image on the monitor. 3.
- Page 13 3.1 VIDOE FORMAT You can set the video format as 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps. 3.2 LANGUAGE Supports English. 3.3 EXPOSURE Exposure describes the brightness-related parameters, which can be adjusted by EXPOSURE MODE, and AGC. EXPOSURE GLOBAL EXPOSURE MODE ...
- Page 14 DAY/NIGHT B & W MODE IR LIGHT SMART IR BACK EXIT SAVE & EXIT Figure 3-4 B & W IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from...
-
Page 15: Video Settings
3.5 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SARUTATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE & EXIT Figure 3-6 VIDEO SETTINGS WHITE BALANCE White balance, the white rendition function of the... -
Page 16: Factory Default
SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light conditions and delivering more accurate and sharp image.
