RGBlink FLEX DS1 User Manual page 17

Note:
The max size of the video is 1920×1080.

There should be one video on a canvas at a time.

A maximum of 6 widgets can be used on a canvas at a time.

(3) Right click the file on the canvas to check and set parameters:
Media duration (sec): set the play duration.
X (pixel): set the horizontal position of the layer.
Y (pixel): set the vertical position of the layer.
Width: set the width of the layer.
Height: set the height of the layer.
Layer order: set the order of layers when there are two or more layers; a greater number means
an upper layer.
Transition type: 8 types of transition are available: Push From Right to Left, Push From Left to
Right, Push From Down to Up, Push From Up to Down, Box In, Box Out, Fade in and Fade out.
User can also disable the function.
Chapter 3: Using Your Product
12
