Summary of Contents for Denon DN-X100

  • Page 2 For U.S.A., Canada, Europe, U.K., Asia, China, Taiwan R.O.C., Korea & Japan model Ver. 1 SERVICE MANUAL DN-X100 MODEL DJ MIXER 注 意 サービスをおこなう前に、このサービスマニュアルを 必ずお読みください。本機は、火災、感電、けがなど に対する安全性を確保するために、さまざまな配慮を おこなっており、また法的には「電気用品安全法」に もとづき、所定の許可を得て製造されております。 従ってサービスをおこなう際は、これらの安全性が維 持されるよう、このサービスマニュアルに記載されて いる注意事項を必ずお守りください。  本機の仕様は性能改良のため、予告なく変更すること For purposes of improvement, specifications and ● ●  があります。...
  • Page 3 DN-X100 SAFETY PRECAUTIONS The following check should be performed for the continued protection of the customer and service technician. LEAKAGE CURRENT CHECK Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check.
  • Page 4 DN-X100 DISASSEMBLY (Follow the procedure below in reverse order when reassembling.) 1. Top Panel (1) Pull out the Knobs from the Top Panel. (2) Remove the 6 screws attaching the Top Panel. (3) Pull up the Top Panel.
  • Page 5 DN-X100 2. Crossfader Unit (1) Remove the 2 screws attaching the Crossfader Unit. (2) Pull up the Crossfader Unit and disconnect the connector. Note: Be careful in the attachment direction. 3. Channel Fader Unit (1) Remove the 3 screws attaching the Channel Fader Unit.
  • Page 6 DN-X100 4. Input Selector Unit (1) Remove the 2 screws attaching the Input Selector Unit. (2) Pull up the Input Selector Unit and disconnect the connector. Note: Be careful in the attachment direction. 5. Top Panel Unit (1) Remove the 6 screws from the both-sides side.

  • Page 7: Block Diagram

    DN-X100 BLOCK DIAGRAM...
  • Page 8 DN-X100 SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. 主な半導体を記載しています。汎用の半導体は記載を省略しています。 1. IC’s MAX003 (IC801) MAX003 Terminal Function Pin Name Symbol Int Pu Function VCL(capacitor between this pin and GND)in 5V operation models,and as Vcc in 3V operation models.
  • Page 9 LEDFX2 PGM2 EFFECT LOOP LED control. (DN-X300 only) FX1SW PGM1 EFFECT LOOP ON/OFF SW 'L' : ON (DN-X300 only) DN-X100/300 program selected Pin 'L' : DN-X300 _STBY _STBY When driven low,this pin forces a transition to hardware standby mode. _RES...
  • Page 10 DN-X100 Pin Name Symbol Int Pu Function Not used Not used CH1REV CH1 FADER REVERSE SW 'L' : ON P84,_CS Chip select signal. GND(0V) CFREV CROSSFADER REVERSE SW 'L' : ON CH2REV CH2 FADER REVERSE SW 'L' : ON CH2FS...
  • Page 11 DN-X100 LB1482M (IC701) 8P/5P AC/DC MUTE CH1 IN A GND LB1482M DC IN CH2 IN Vcc1 Vcc2 AC IN (1) CH1 IN PEAK HOLD CH2 IN AC IN (2) LOGIC DC IN DC IN Vcc1 (Signal system) Inside LOGIC reference...
  • Page 12 DN-X100 M51132L (IC109, 209) Input 2 Output 2 Control mode switching Bus Through/VCA change SW Balance/Volume 2 control Shock noise reduction at Bus Through SW switching Volume/Volume 1 control Filter Output 1 Input 1 Power 1M FLASH MEMORY (IC802) ADG212A (IC113, 213)
  • Page 13 DN-X100 PRINTED WIRING BOARDS MIXER P.W.B. UNIT COMPONENT SIDE...
  • Page 14 DN-X100 FOIL SIDE...

  • Page 15: Output P.w.b. Unit

    DN-X100 OUTPUT P.W.B. UNIT COMPONENT SIDE FOIL SIDE...

  • Page 16: Jack P.w.b. Unit

    DN-X100 JACK P.W.B. UNIT COMPONENT SIDE FOIL SIDE...

  • Page 17: Cpu P.w.b. Unit

    DN-X100 CPU P.W.B. UNIT COMPONENT SIDE FOIL SIDE...
  • Page 18 DN-X100 REVERSE P.W.B. UNIT PHONE P.W.B. UNIT COMPONENT SIDE COMPONENT SIDE FADER START P.W.B. UNIT COMPONENT SIDE CH VR P.W.B. UNIT TRANS P.W.B. UNIT COMPONENT SIDE FOIL SIDE COMPONENT SIDE FOIL SIDE...

  • Page 19: Note For Parts List

    DN-X100 NOTE FOR PARTS LIST Part indicated with the mark " " are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused. When ordering of part, clearly indicate "1" and "I" (i) to avoid mis- supplying.

  • Page 20: Parts List Of P.w.b. Unit

    DN-X100 PARTS LIST OF P.W.B. UNIT ＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります Note: The symbols in the column "Remarks" indicate the following destinations. E3: U.S.A. & Canada model E2: Europe model EK: U.K. model E2A: Asia model E1C: China model EUT: Taiwan R.O.C. model E1K: Korea model JP: Japan model MIXER P.W.B.
  • Page 21 DN-X100 Ref. No. Part No. Part Name Remarks Q'ty CAPACITORS GROUP 00D 958 7032 806 ELEC. CAPACITOR(100uF/16V,M) C118 00D 958 7029 107 CERAMIC CAPACITOR(0.1uF/50V,Z) C119,120 00D 958 7033 902 ELEC. CAPACITOR(1uF/50V,M) C121,122 00D 958 7030 808 CHIP CAPACITOR(100pF/50V,J) C125,126 00D 958 7032 204 POLYESTER CAPACITOR(0.0082uF/50V,J)
  • Page 22 DN-X100 Ref. No. Part No. Part Name Remarks Q'ty C319 00D 958 7030 507 ELEC. CAPACITOR(10uF/50V,M) C320 00D 958 7030 109 CHIP CAPACITOR(220pF/50V,J) C402 00D 958 7029 107 CERAMIC CAPACITOR(0.1uF/50V,Z) C407,408 00D 958 7030 303 CHIP CAPACITOR(22pF/50V,J) C409,410 00D 958 7030 002...
  • Page 23 DN-X100 OUTPUT P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty SEMICONDUCTORS GROUP IC01 00D 958 7035 502 IC(NJM7815FA) IC02 00D 941 0021 405 IC(NJM7915FA) IC03 00D 958 0040 303 IC 7805 IC101 00D 958 7036 200 IC(NJM-4580M)
  • Page 24 DN-X100 Ref. No. Part No. Part Name Remarks Q'ty OTHER PARTS GROUP CN03 00D 958 7017 504 4P SOCKET CN04 00D 958 7017 708 4P SOCKET CN05 00D 958 7017 504 4P SOCKET CN06 00D 958 7037 801 RJ45 JACK...
  • Page 25 DN-X100 JACK P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty SEMICONDUCTORS GROUP IC301 00D 958 7035 803 IC(NJM-2068M) IC952 00D 958 7035 900 IC(NJM-2060V) Q956-959 00D 958 7034 707 TRANSISTOR(2SC2878-B) CAPACITORS GROUP C301,302 00D 958 7032 408 ELEC.
  • Page 26 DN-X100 CPU P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty SEMICONDUCTORS GROUP IC801 00D 958 7035 405 IC(MAX003) IC802 00D 958 7014 400 CPU IC ASS'Y IC(W39F010P-70B) IC803 00D 958 7035 609 IC(BD4745G) RESISTORS GROUP RB801 00D 958 7022 405...
  • Page 27 DN-X100 CROSSFADER P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty RESISTORS GROUP VR01 00D 958 7037 005 SLIDE VR(RA45D2-211-15D1-R0B50K) OTHER PARTS GROUP W801A 00D 958 7017 601 4P SOCKE 00D 958 7022 900 FIXED PLATE FOR SLIDE VR...
  • Page 28 DN-X100 FADER START P.W.B. UNIT ASS'Y Ref. No. Part No. Part Name Remarks Q'ty OTHER PARTS GROUP SW801-804 00D 958 7015 409 SLIDE SW(SSSF122NA1-HF,6PIN) W805 00D 958 7023 501 5P CONNECTOR WIRE REVERSE P.W.B. UNIT ASS'Y Ref. No. Part No.

  • Page 29: Exploded View

    DN-X100 EXPLODED VIEW Parts List WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.  印の部分は安全を維持するために重要 な部品です。従って交換時は必ず指定の 部品を使用してください。...

  • Page 30: Parts List Of Exploded View

    DN-X100 PARTS LIST OF EXPLODED VIEW ＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。 Note: The symbols in the column "Remarks" indicate the following destinations. E3: U.S.A. & Canada model E2: Europe model EK: U.K. model E2A: Asia model E1C: China model EUT: Taiwan R.O.C. model E1K: Korea model JP: Japan model Ref.

  • Page 31: Packing View

    DN-X100 PACKING VIEW 4 ~ 7 PARTS LIST OF PACKING & ACCESSORIES ＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。 Note: The symbols in the column "Remarks" indicate the following destinations. E3: U.S.A. & Canada model E2: Europe model EK: U.K. model E2A: Asia model E1C: China model EUT: Taiwan R.O.C.

  • Page 32: Note For Schematic Diagram

    DN-X100 NOTE FOR SCHEMATIC DIAGRAM 配線図について WARNING: ! 印の部品は安全を維持するために重要な部品です。 Parts marked with this symbol ! have critical characteristics. 従って交換時は必ず指定の部品を使用してください。 Use ONLY replacement parts recommended by the manufactur- 注） CAUTION: (1) 指定なき抵抗値は Ω、ｋ は ｋΩ、M は MΩ を示す。 Before returning the unit to the customer, make sure you make (2) 指定なきコンデンサーの値は...
  • Page 33 DN-X100 SCHEMATIC DIAGRAMS (1/3) MIXER PCB R543 C529 ZD501 8.2B CN01 ZD502 C530 8.2B C525 R544 R537 -15V 100/25 R521 R525 C515 C502 3.9K CUE PAN IC506A C505 R505 R513 VR501A IC505B 4.7/50 IC504A 4556D SW103 20KB C513 R523 R527...
  • Page 34 DN-X100 SCHEMATIC DIAGRAMS (2/3) CPU PCB R805 R806 PC1A PC1B TO OUTPUT PCB PC2A PC2B C810 R807 R808 CN04 CH REV /RST TO MIXER PCB IC802 W39F010B-70 IC803 C811 CH VR PCB R826 R812 100/10 W801A W801 VR01A VR01B C812 BD4745G 2.2/50...
  • Page 35 DN-X100 SCHEMATIC DIAGRAMS (3/3) OUTPUT PCB D855 D851 1N4002 1N4002 JACK PCB D857 D853 JK851 R851 1N4002 1N4002 PLAY CONTROL1 CN07 PC1A C323 C303 C301 IC301B 100P PC1B 100P JK301 R301 R852 C305 PC2A C324 2068 PC2B 22/16 R303 4.7/50...
