  • Page 1 ULTRA ™ owners manual FURNITURE DESIGN U-232...

  • Page 3: Table Of Contents

    CONTENTS CONTENTS Advisory ........................4 Acoustics ........................6 Fabric Cleaning Information ..................6 Installation ......................... 7 Power Down Operation ....................17 Remote Control Function .................... 19 Remote Control Programming ..................20 USB Outlets ......................23 Troubleshooting ......................24 Accessories ....................... 25 1-3-25 Warranty ......................

  • Page 4: Advisory

    ADVISORY IMPORTANT INFORMATION READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT PRODUCT RATINGS The base lift motors are not designed for continuous WARNING WARNING use. Reliable operation and full life expectancy will be realized as long as the lift motor operation FOR OPTIMUM ADJUSTABLE BASE does not exceed five (5) minutes over a fifty (50) OPERATION, USE A GROUNDED, ELECTRICAL...
  • Page 5 ADVISORY IMPORTANT INFORMATION READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT FCC COMPLIANCE PACEMAKER WARNING The equipment has been tested and found to comply This product produces a vibrating sensation. with the limits for a Class B digital device, pursuant to It is possible that individuals with heart-assist Part 15 of the FCC Rules.

  • Page 6: Acoustics

    ACOUSTICS LIFTING/LOWERING MECHANISMS LOCATION ENVIRONMENT The lift/lower feature will emit a minimal The level of sound experienced during operation humming sound during operation. This is normal. is directly related to the location environment. For example, when a base is located on a hardwood During operation, the lift arm wheels make contact floor with the massage feature in operation, a with the platform support of the base.

  • Page 7: Installation

    INSTALLATION For installation and setup, complete the following procedures, in the order indicated below and on the following pages: STEP 1 Before discarding any packing materials, check the adjustable base shipping carton and verify the following items are included: • (4) Bed Legs •...
  • Page 8 INSTALLATION INSTALLATION STEP 2 Remove the hardware box. Cut zip-tie and remove WARNING WARNING mattress retainer. AT LEAST TWO PEOPLE ARE STEP 3 RECOMMENDED FOR HANDLING AND Install (4) legs into the base frame. Simply screw each leg MOVING ADJUSTABLE BASE. into a tapped hole at the corner of the base frame (FIGURE 2).
  • Page 9 INSTALLATION STEP 5 Remove the plastic packaging from the base frame. Carefully rotate the adjustable base over to position the base so it is resting on its legs. STEP 6 Plug electrical power cord into a working, grounded electrical outlet. Note: An electrical surge protection device is recommended (not included).
  • Page 10 INSTALLATION STEP 9 Install corner mattress retainers at the foot end of the adjustable base as follows: a. Locate by feel corner holes underneath base cover at foot end of base (FIGURE 4). b. Insert two-pronged bushing into holes in corner mattress retainer. Press bushing through material into holes until retainer fi ts securely against base (FIGURES 5 and 6).
  • Page 11 INSTALLATION HEADBOARD BRACKET INSTALLATION NOTE FAILURE TO FOLLOW HEADBOARD BRACKET INSTALLATION INSTRUCTIONS MAY CAUSE HEADBOARD BRACKET INTERFERENCE WITH BASE FOAM DURING BASE OPERATION. BASE FOAM OR BASE COVER DAMAGE COULD RESULT. WARNING IN ORDER TO AVOID A PERSON OR PET BEING CAUGHT IN THE SPACE REFERENCED BELOW WHILE THE BASE IS IN MOTION, THE BOTTOM OF THE HEADBOARD CROSS MEMBER MUST...
  • Page 12 INSTALLATION STEP 10 Install headboard brackets to the adjustable base frame as follows: a. Using the remote control, raise the head section of the base as far as it will articulate to gain access to the adjustable base frame. b. Insert a 1/2” carriage bolt into a headboard bracket weldment (FIGURE 8).
  • Page 13 INSTALLATION c. Locate (2) holes in base frame at one corner of head end of base. Place the headboard bracket weldment underneath base frame and against the head end of the base, positioning the bracket weldment so the carriage bolt appears through the innermost hole in the base frame (FIGURE 9).
  • Page 14 INSTALLATION d. Place headboard fl ange weldment against headboard bracket weldment. Install (2) 1” long hex bolts through slots in headboard bracket weldment and holes in headboard fl ange weldment (FIGURES10 and 11). Secure using (2) hex nuts. Loosely tighten to allow adjustment for headboard hole alignment.
  • Page 15 AND NUTS HEADBOARD FLANGE WELDMENT h. Firmly tighten all bolts of both headboard bracket assemblies. i. Install headboard. STEP 11 Install mattress on adjustable base. Typical U-232 adjustable base installation is now complete. ULTRA owners manual 99301592 ™ furniture design...

  • Page 16: Power Down Operation

    POWER DOWN OPERATION To lower the base to the fl at position during an electrical power outage, complete the following procedure: STEP 1 Verify power is unplugged from electrical power source. STEP 2 Locate (1) power brick (FIGURE 13) and (2) 9 volt batteries (not included).
  • Page 17 POWER DOWN OPERATION STEP 4 Press the head down button on the remote control until the head section is fl at, then press the foot down button on the remote control until the foot section is fl at (FIGURE 15). FIGURE 15 HEAD FOOT...

  • Page 18: Remote Control Function

    REMOTE CONTROL FUNCTION UNDERBED LIGHT BUTTON SNORE BUTTON Press to turn underbed light on. Press Press and hold to raise head to the again to turn underbed light off. preprogrammed position. Head will automatically lower to fl at after 15 LOCK BUTTON minutes.

  • Page 19: Remote Control Programming

    REMOTE CONTROL PROGRAMMING (1 remote control - 1 base) Program One Remote to Operate One Base - perform the following numbered procedure. STEP 1 Unplug the adjustable base electrical power cord from power source. Wait 30 seconds, then plug back in. STEP 2 FIGURE 18 Remove the battery compartment door from the...
  • Page 20 REMOTE CONTROL PROGRAMMING (1 or 2 remote controls - 2 bases) Program One Remote to Operate Two Bases (Tandem Syncing) - perform the following numbered procedure. Note: Make sure both remotes are in “press & hold” mode and both bases are fl at before beginning procedure.
  • Page 21 REMOTE CONTROL PROGRAMMING (separating 2 bases) Separate Two Bases - for independent adjustable base movement, perform the following numbered procedure. STEP 1 BASE 1 Unplug both bases from electrical power outlet. Position REMOTE 1 both bases on their sides, in close proximity to each other. CAUTION: AT LEAST TWO PEOPLE ARE RECOMMENDED FOR HANDLING AND MOVING ADJUSTABLE BASE.

  • Page 22: Usb Outlets

    USB OUTLETS USB OUTLETS These bases are equipped with (2) working USB outlets located on either side of the base that allow you to charge low voltage electronic devices such as cell phones, tablets, and/or laptops directly from the base (FIGURE 27). Note: USB outlet is for charging convenience only.

  • Page 23: Troubleshooting

    TROUBLESHOOTING If the adjustable base fails to operate, investigate the symptoms and possible solutions provided in the chart below: SOLUTION SYMPTOM • Verify power cord is plugged into a working, grounded Remote control illuminates and appears to be electrical outlet. A grounded, electrical surge protection device is recommended.

  • Page 24: Accessories

    ACCESSORIES OPTIONAL EQUIPMENT Contact customer service toll free (800-888-3078) to order the accessories indicated in the chart below. ACCESSORY DESCRIPTION CODE IMAGE Head Board Brackets-TXL Head Board Brackets-FXL/Q Bed Link Kit (connects two bases together) 4B7410 Swing-away Hinges (headboard required for use, 4B1209 cannot be used with bed straps) ULTRA...

  • Page 25: Warranty

    1 YEAR, 3 YEAR AND 25 YEAR LIMITED WARRANTY In this warranty: “Adjustable base” means the adjustable bed foundation sold by L&P to the dealer. The “adjustable base” does not include the mattress. “L&P” means Leggett & Platt, Incorporated. “Purchaser” and “You” both mean the consumer who is the original purchaser of this adjustable base made by L&P.
  • Page 26 1 YEAR, 3 YEAR AND 25 YEAR LIMITED WARRANTY Repair or replacement shall be the sole remedy of the L&P makes no other warranty whatever, express or Purchaser. There shall be no liability on the part of L&P implied, and all implied warranties of merchantability and for any special, indirect, incidental, or consequential fitness for a particular purpose are disclaimed by L&P and damages or for any other damage, claim, or loss not...
  • Page 28 99301592 EDR13436 2/16 NATIONWIDE CUSTOMER SERVICE (800) 888-3078 toll free: © 2016 Leggett & Platt Adjustable Bed Group, a division of Leggett & Platt Incorporated...
