The Network configuration
xConfiguration Network [1..1] Link Network
Set the Ethernet link speed for the network.
Value space: <Auto/10half/10full/100half/100full/1000full>
Auto: Autonegotiate link speed.
10half: Force link to 10 Mbps half-duplex.
10full: Force link to 10 Mbps full-duplex.
100half: Force link to 100 Mbps half-duplex.
100full: Force link to 100 Mbps full-duplex.
1000full: Force link to 1 Gbps full-duplex.
Example: xConfiguration Network 1 Link Network: Auto
xConfiguration Network [1..1] Link Endpoint
Set the Ethernet link speed for the endpoint (video system).
Value space: <Auto/10half/10full/100half/100full/1000full>
Auto: Autonegotiate link speed.
10half: Force link to 10 Mbps half-duplex.
10full: Force link to 10 Mbps full-duplex.
100half: Force link to 100 Mbps half-duplex.
100full: Force link to 100 Mbps full-duplex.
1000full: Force link to 1 Gbps full-duplex.
Example: xConfiguration Network 1 Link Endpoint: Auto
xConfiguration Network [1..1] Assignment
Define whether to use DHCP or Static IPv4 assignment.
<Static/DHCP>
Value space:
Static: Set the network assignment to Static and configure the static IPv4 settings (IP Address,
SubnetMask and Gateway).
DHCP: The system addresses are automatically assigned by the DHCP server.
xConfiguration Network 1 Assignment: DHCP
Example:
xConfiguration Network [1..1] DNS Domain Name
DNS Domain Name is the default domain name suffix which is added to unqualified names.
Example: If the DNS Domain Name is "domain.com" and the name to lookup is "MyVideoSystem",
this will result in the DNS lookup "MyVideoSystem.domain.com".
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 DNS Domain Name: ""
D14953.01 ISDN Link API Reference Guide IL1.0 June 2012.
© 2012 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration Network [1..1] DNS Server [1..3] Address
xConfiguration Network [1..1] IPStack
xConfiguration Network [1..1] IPv4 Address
xConfiguration Network [1..1] IPv4 Gateway
xConfiguration Network [1..1] IPv4 SubnetMask
30
xCommand
Define the network addresses for DNS servers. Up to 3 addresses may be specified. If the network
addresses are unknown, contact your administrator or Internet Service Provider.
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 DNS Server 1 Address: ""
Select which internet protocols the system will support.
Value space: <IPv4/IPv6>
IPv4: IP version 4 is supported.
IPv6: IP version 6 is supported, and the IPv4 settings (IP Address, IP Subnet Mask and Gateway)
will be disabled.
Example: xConfiguration Network 1 IPStack: IPv4
Enter the static IPv4 network address for the system. Only applicable if the Network Assignment is set
to Static.
Value space: <S: 0, 64>
Format: Only the valid IP address format is accepted. Any IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
xConfiguration Network 1 IPv4 Address: "192.0.2.0"
Example:
Define the IPv4 network gateway. Only applicable if the Network Assignment is set to Static.
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: xConfiguration Network 1 IPv4 Gateway: "192.0.2.0"
Define the IPv4 network subnet mask. Only applicable if the Network Assignment is set to Static.
<S: 0, 64>
Value space:
Format: Compact string with a maximum of 64 characters.
Example: xConfiguration Network 1 IPv4 SubnetMask: "255.255.255.0"
