Cisco TelePresence ISDN Link Reference Manual page 29

Cisco TelePresence ISDN Link
Contents Introduction
xConfiguration ISDN BRI ChanId
Select if BRI Channel ID information should be sent to the PXB.
Value space: <On/Off>
On: When set to On, the system will signal to the PBX which BRI channels is used for the call.
Note: This setting must be set to On, to work with an Ericsson MD110 PBX.
Off: When set to Off, Channel ID information is not sent. Default setting is Off.
Example: xConfiguration ISDN BRI ChanId: Off
xConfiguration ISDN BRI InterfaceSearch
Selects whether to start searching for available B-channels from the highest numbered interface or
from the lowest numbered interface.
<High/Low>
Value space:
High: When set to High, the system will start searching for available B-channels from the highest
numbered interface.
Low: When set to Low, the system will start searching for available B-channels from the lowest
numbered interface.
xConfiguration ISDN BRI InterfaceSearch: High
Example:
xConfiguration ISDN BRI SwitchType
Select the type of BRI switch the system is connected to.
Value space: <NI/ATT/Euro/Japan/1TR6/Australia/FETEX>
NI: Select NI if the switch is a National ISDN switch type.
ATT: Select ATT if the switch is an AT&T (for the U.S.) ISDN switch type.
Euro: Select Euro if the switch is an Euro (UK and others) ISDN switch type.
Japan: Select Japan if the switch is a Japanese ISDN switch type.
1TR6: Select 1TR6 if the switch is an 1TR6 switch type.
Australia: Select Australia if the switch is an Australian ISDN switch type.
FETEX: Select FETEX if the switch is a FETEX ISDN switch type.
Example: xConfiguration ISDN BRI SwitchType: Euro
xConfiguration ISDN BRI AutoActivation
Set the auto activation mode of the BRI interface (ISDN Layer 1).
Value space: <Off/Selected/All>
Off: When set to Off, no interfaces will be activated.
Selected: When set to Selected, the system will activate the interfaces which are already on.
All: When set to All, the system will activate all interfaces regardless of status.
Example: xConfiguration ISDN BRI AutoActivation: All
D14953.01 ISDN Link API Reference Guide IL1.0 June 2012.
© 2012 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration ISDN BRI MaxDeactiveTime
xConfiguration ISDN BRI Interface [1..4] Mode
xConfiguration ISDN BRI Interface [1..4] DirectoryNumber [1..2] Number
xConfiguration ISDN BRI Interface [1..4] SPID [1..2] Number
29
xCommand
Set the maximum duration for Layer 1 in de-active state before auto activation (re)starts.
Value space: <1..60>
Range: Select a value between 1 and 60 seconds.
xConfiguration ISDN BRI MaxDeactiveTime: 5
Example:
Select BRI interface 1 to 4, and set the BRI interface mode.
Value space: <On/Off>
On: Set to On to enable the selected BRI interface.
Off: Set to Off to disable the selected BRI interface.
Example: xConfiguration ISDN BRI Interface 1 Mode: Off
Configure the Directory Numbers for the various BRI interfaces.
Value space: <S: 0, 24>
Format: String with a maximum of 24 characters.
xConfiguration ISDN BRI Interface 1 DirectoryNumber 1 Number: ""
Example:
Configure the SPID Numbers for the various BRI interfaces.
Value space: <S: 0, 20>
Format: String with a maximum of 20 characters.
Example: xConfiguration ISDN BRI Interface 1 SPID 1 Number: ""
