xConfiguration ISDN PRI NSFVideoTelephony Mode
Configure the NSF (Network Service Facility) mode for video telephony.
Value space: <On/Off>
On: Set to On, to enable Network Service Facility for video telephony.
Off: Set to Off, to disable Network Service Facility for video telephony.
Example: xConfiguration ISDN PRI NSFVideoTelephony Mode: Off
xConfiguration ISDN PRI NSFVideoTelephony Number
Defines what Service Facility to use for video telephony. Requires NSFVideoTelephony Mode set to
On.
<0..31>
Value space:
Range: Select a value between 0 and 31.
Example: xConfiguration ISDN PRI NSFVideoTelephony Number: 0
xConfiguration ISDN PRI Interface [1..1] MaxChannels
Set the maximum number of channels the system may use at any given time.
Value space: <1..30>
Range: Select a value between 1 and 30.
xConfiguration ISDN PRI Interface 1 MaxChannels: 23
Example:
xConfiguration ISDN PRI Interface [1..1] HighChannel
Set the highest numbered B-channel that may be used by the system when selecting channels for
outgoing calls.
Value space: <1..31>
Range: Select a value between 1 and 31.
Example: xConfiguration ISDN PRI Interface 1 HighChannel: 31
xConfiguration ISDN PRI Interface [1..1] LowChannel
Set the lowest numbered B-channel that may be used by the system when selecting channels for
outgoing calls.
<1..31>
Value space:
Range: Select a value between 1 and 31.
Example: xConfiguration ISDN PRI Interface 1 LowChannel: 1
D14953.01 ISDN Link API Reference Guide IL1.0 June 2012.
© 2012 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration ISDN PRI Interface [1..1] Search
xConfiguration ISDN PRI Interface [1..1] NumberRangeStart
xConfiguration ISDN PRI Interface [1..1] NumberRangeStop
xConfiguration ISDN BRI Alert
28
xCommand
Selects whether to start searching for available B-channels from the highest numbered channel or
from the lowest numbered channel.
Value space: <High/Low>
High: When set to High, the system will start searching for available B-channels from the highest
numbered channel.
Low: When set to Low, the system will start searching for available B-channels from the lowest
numbered channel.
Example: xConfiguration ISDN PRI Interface 1 Search: High
If the PRI line has a range of numbers, the first number in the range should be entered in the Number
Range Start field.
<S: 0, 24>
Value space:
Format: String with a maximum of 24 characters.
Example: xConfiguration ISDN PRI Interface 1 NumberRangeStart: ""
If the PRI line has a range of numbers, the last number in the range is entered in the Number Range
Stop field.
Value space: <S: 0, 24>
Format: String with a maximum of 24 characters.
xConfiguration ISDN PRI Interface 1 NumberRangeStop: ""
Example:
Select if the system should respond with an alert message to all incoming setup messages, or to the
first incoming channel only.
Value space: <On/Off>
On: When set to On, the system will respond with an alert message to all incoming setup
messages.
Off: When set to Off (default) the system will respond with an alert message only to the incoming
setup message related to the initial channel. Note that if the PBX requires this signalling you will
only get connected on the first incoming channel.
Example: xConfiguration ISDN BRI Alert: Off
