6.6.6.1

Save parameter set

6.6.6.2

Load parameter set

6.6.7

Monitoring functions

Calibration request
Particle protection
• Main Menu > Settings
Save the current parameter settings.
Softkey 4: Edit a file name
Rename the parameter set.
• Main Menu > Settings
selected
The settings of the
reloaded.
Softkey 6: Arrow up
Upward to the previous screen.
Softkey 7: Arrow down
Downward to the next screen.
• Main Menu > Settings
• Main Menu > Settings
It can be selected whether the operator is reminded of the fact that a calibration may
has become necessary or not. The default value is off.
Softkey 3: Off
The calibration request will be switched off.
Softkey 7: ON
The calibration request will be switched on.
If the calibration request is switched on, a corresponding message will appear when
30 minutes have elapsed after power on or if the temperature of the UL5000 has
changed by more than 5 °C (9 °F) since the last calibration.
• Main Menu > Settings
This mode can be switched on and off.
If switched on the UL5000 will not start pumping down before the inlet ha
1
dropped below mbar. I. e. it is assumed that the part under test is pumped by
another pump in parallel.
Purpose: When the leak detector does not pump at high pressures no gas stream
possibly carrying particles gets into the leak detector.
> Parameter save / load
> Parameter save / load
saved parameter set will be displayed and can be
> Monitoring functions
> Monitoring functions > Calibration request
> Monitoring functions > Particle protection
> Save
> Save parameter set
s not
Description of the Menu
,
