In the backup condition the RTC block will function to as low as 1.1V on the VRTC
pin. The RTC draws 10µA typically during powered backup (15µA max).
Figure 5.20 1 shows the VRTC connectivity arrangement.
Figure 29: VRTC connection
TIP
GR64 Integrators Manual
Page: 80/104
Recommended button cell to use is Seiko TS414H. This is a lead-free,
reflowable SMT Lithium battery with a nominal voltage of 1.5V.
