Wavecom GR64 GSM/GPRS Integrator's Manual page 32

GR64 Integrators Manual
Page: 32/104
Pin Name
37 DTR1/GPIO10
38 DCD1/GPIO11
39 RTS1/GPIO9
40 CTS1/GPIO12
41 DTM1
42 DFM1
43 DTM3
44 DFM3
45 USBDP
46 USBDN
47 SSPDTM
48 SSPDFM
49 VUSB
50 ALARM
51 SSPFS
52 SSPCLK
53 MICIP
54 MICIN
55 EARP
56 EARN
57 AUXO
58 SERVICE
59 AUXI
60 AREF
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement.
Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable
Unused pin termination
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Leave Open
Connect to AREF
Connect to AREF
Leave Open
Leave Open
Leave Open
Ground
Connect to AREF
Leave Open
