Chenbro 80H10220919A0 User Manual

Server chassis 4-ports sata iii backplane
Hide thumbs

Advertisement

Quick Links

4-Port SATA III Backplane 80H10220919A0 User's Manual
CHENBRO
Server Chassis
4-Ports SATA III Backplane
User's Manual
80H10220919A0
Dec / 03 / 2013
st
15F., No.150, Jian 1
Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.)
Tel: +886-2-82265500
Fax: +886-2-82265392
Email: info@chenbro.com.tw
1

Advertisement

loading

Related Manuals for Chenbro 80H10220919A0

Summary of Contents for Chenbro 80H10220919A0

  • Page 1 4-Port SATA III Backplane 80H10220919A0 User’s Manual CHENBRO Server Chassis 4-Ports SATA III Backplane User’s Manual 80H10220919A0 Dec / 03 / 2013 15F., No.150, Jian 1 Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.) Tel: +886-2-82265500 Fax: +886-2-82265392 Email: info@chenbro.com.tw...

  • Page 2: Copyright

    Chenbro Micom Co., Ltd. reserves the right to make improvement and modification to the products indicated in this manual at any time. Specifications are therefore subject to change without prior notice.

  • Page 3: Table Of Contents

    4-Port SATA III Backplane 80H10220919A0 User’s Manual Contents Copyright……………………………………………………………………………………………..2 Technical Support……………………………………………………..…………………………………2 Revision History………………………………………………………………………………………….4 Hardware Specification………………………………………………………………………………… 5 Accommodated Chassis………………………………………………………………………………..5 Backplane Photos………………………………………………………………………………………..6 Backplane Layout………………………………………………………………………………………..7 Backplane wiring……………………………………………………………………………………….11 15F., No.150, Jian 1 Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.) Tel: +886-2-82265500 Fax: +886-2-82265392 Email: info@chenbro.com.tw...

  • Page 4: Revision History

    4-Port SATA III Backplane 80H10220919A0 User’s Manual Revision History Date Modifications  Sep / 15 / 2010 First release  Dec / 03 / 2013 Add CN06 SGPIO Pin Assignment 15F., No.150, Jian 1 Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.)

  • Page 5: Hardware Specification

    SATA / SAS Hot-Swap Yes, allows user to on line replace Hard Disk Drive LED indicates Hard Disk Drive status ( Defined by Chenbro ) Power LED – Blue ( When HDD is present ) Display Access LED –Green ( When HDD is busy ) Error LED –Red ( When HDD is fail )

  • Page 6: Backplane Photos

    4-Port SATA III Backplane 80H10220919A0 User’s Manual Backplane photos Front side Rear side 15F., No.150, Jian 1 Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.) Tel: +886-2-82265500 Fax: +886-2-82265392 Email: info@chenbro.com.tw...

  • Page 7: Backplane Layout

    4-Port SATA III Backplane 80H10220919A0 User’s Manual Backplane Layout Front view ( HDD slot IN ) [CN11 / CN21 / CN31 / CN41]: connect to 29pin SAS or 22pin SATA II HDD 2. [LD11 / LD21 / LD31 / LD41]: Blue LED indicate HDD Power, 3.
  • Page 8 4-Port SATA III Backplane 80H10220919A0 User’s Manual Rear View ( Host Connectors IN ) 4. [CN12 / CN22 / CN32 / CN42]: connect to 7pin SATA II host 5. [JF1 / JF2]: 3P3C Fan connector Pin1 Pin1 15F., No.150, Jian 1 Rd.,Zhonghe Dist.,New Taipei City, Taiwan( R.O.C.)
  • Page 9 4-Port SATA III Backplane 80H10220919A0 User’s Manual 6. [JP1]: Power failure signal ( To Redundant Power Supply ) 7. [JM1]: Power Failure Alarm Mute ( To Redundant Power Supply ) Pin1 Pin1 [F0104]: Discrete HDD Fail LED Signal Input connector ( From RAID Card )
  • Page 10 4-Port SATA III Backplane 80H10220919A0 User’s Manual [SW1]: Fan & Temperature setting [CN04]: SGPIO HDD access function jumper [CN05]: SGPIO HDD fail function jumper CN05 CN04 SGPIO Pin B8 Signal Close Close Enable HDD failure and activity signal via SGPIO...

  • Page 11: Backplane Wiring

    4-Port SATA III Backplane 80H10220919A0 User’s Manual Backplane Wiring To M/B SGPIO connector To M/B To M/B To front Bezel To M/B To RAID card To Fan To R/PSU SATA 7pin Cable Fan cable standard big 4pin power HDD Fail LED Signal Input...
