03-M-E3B, 03-M-DI-E3B, 03-M-E3BG WSM
Cam Height (Continued)
1. Measure the height of the cam at its highest point with an outside
micrometer.
2. If the measurement is less than the allowable limit, replace the
camshaft.
Factory
spec.
Cam height of
exhaust
Allowable
limit

Oil Clearance of Camshaft Journal

1. Measure the camshaft journal O.D. with an outside micrometer.
2. Measure the cylinder block bore I.D. for camshaft with a cylinder
gauge, and calculate the oil clearance.
3. If the oil clearance exceeds the allowable limit, replace the
camshaft.
Factory spec.
Oil clearance of
camshaft journal
Allowable limit
Camshaft journal O.D. Factory spec.
Cylinder block bore I.D. Factory spec.
S-84
DIESEL ENGINE
33.00 mm
V2403-M-DI-T
1.299 in.
V2403-M-T
D1703-M-BG 33.27 mm
V2003-M-BG 1.310 in.
V2203-M-BG
D1503-M
33.47 mm
V2003-M
1.318 in.
V2003-M-T-BG
D1703-M
D1803-M
V2203-M
33.90 mm
V2403-M
1.335 in.
D1803-M-DI
V2403-M-DI
V2403-M-BG
32.95 mm
V2403-M-DI-T
1.297 in.
V2403-M-T
D1703-M-BG 33.22 mm
V2003-M-BG 1.308 in.
V2203-M-BG
D1503-M
33.42 mm
V2003-M
1.316 in.
V2003-M-T-BG
D1703-M
D1803-M
V2203-M
33.85 mm
V2403-M
1.333 in.
D1803-M-DI
V2403-M-DI
V2403-M-BG
0.050 to 0.091 mm
0.0020 to 0.0035 in.
0.15 mm
0.0059 in.
39.934 to 39.950 mm
1.5722 to 1.5728 in.
40.000 to 40.025 mm
1.5748 to 1.5757 in.
W1111109
W1031662
