Reference Section; Display Mapping - DPS Telecom NetGuardian 832A G5 User Manual

14

Reference Section

14.1

Display Mapping

Port Address Display
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
99 1
Table 14.1.A. Display descriptions and SNMP Trap numbers for the NetGuardian
* The TRAP number ranges shown correspond to the point range of each display. For example, the SNMP Trap
"Set" number for alarm 1 (in Display 1) is 8001, "Set" for alarm 2 is 8002, "Set" for alarm 3 is 8003, etc.
** The TRAP number descriptions for the Analog channels (1-8) are in the following order: minor under, minor
over, major under, and major over. For example, for Analog channel 1, the "Set" number for minor under is
8129, minor over is 8130, major under is 8131, and major over is 8132.
1 Discrete Alarms 1-32
For NG 864 Alarms 1-64
2
3 Analog Channel 1**
4 Analog Channel 2**
5 Analog Channel 3**
6 Analog Channel 4**
7 Analog Channel 5**
8 Analog Channel 6**
9 Analog Channel 7**
10 Analog Channel 8**
11 Relays/System Alarms (See table below)
12 NetGuardian Expansion 1 Alarms 1-48
12 NetGuardian 480 (as DX) Alarms 1-64
13 NetGuardian Expansion 1 Relays 1-8 or
NetGuardian 480 (as DX) Relays 1-4
13 NetGuardian 480 (as DX) Alarms 65-80
14 NetGuardian Expansion 2 Alarms 1-48
15 NetGuardian Expansion 2 Relays 1-8
16 NetGuardian Expansion 3 Alarms 1-48
17 NetGuardian Expansion 3 Relays 1-8
Description
Ping Table
Set Clear
8001-8032 9001-9032
8001-8064 9001-9064
8065-8096 9065-9096
8129-8132 9129-9132
8193-8196 9193-9196
8257-8260 9257-9260
8321-8324 9321-9324
8385-8388 9385-9388
8449-8452 9449-9452
8513-8516 9513-9516
8577-8580 9577-9580
8641-8674 9641-9674
6001-6064 7001-7064
6001-6064 7001-7064
6065-6072 7065-7072
6081-6096 7081-7096
6129-6177 7129-7177
6193-6200 7193-7200
6257-6305 7257-7305
6321-6328 7321-7328
61
