Weiser SmartCode 10 Installation And User Manual page 2

3 Install the exterior touchscreen
A
What is the diameter of the hole in the door?
Diameter is 54 mm Diameter is 38 mm
(2 1/8 in)
or
54 mm
2 1/8 in
"D" is required for installation. "D" is not needed for
Install "D" on "F." installation. Discard "D."
F
D
B
Locate screws for step 3C and keep them within reach.
T
4 Install the interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
Make sure turnpiece is in
the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
L
5
Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in battery pack.
J
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
alkaline batteries only.
C
Install exterior touchscreen and mounting plate.
a
(1 1/2 in)
38 mm
1 1/2 in
D
c
screws evenly.
B
b
L
M
d
K
Do not install batteries
until step 5.
Alarm will sound if
battery is installed
before cable is
L
connected.
B
Make sure the door is open, and
insert the battery pack.
K
2 / 4
actual
size
b
F
Cable goes
underneath latch.
d
Keep parallel to
edge of door.
T
T (2x)
Tighten
Install interior assembly onto mounting plate.
a
b
L
align
Lay excess cable lat inside the
Ensure tight cable
bottom of the interior housing.
connection.
c
d
C
After a few seconds, the latch bolt will retract and extend on
its own to learn the orientation of the door. This is called the
door handing process, and it is crucial to lock operation.
D
If the touchscreen indicates a failure, attempt this procedure again.
If the door handing process is still unsuccessful after a second
attempt, perform the "Manual Door Handing" procedure on page 4.
T
Support exterior
assembly during
mounting plate
installation.
G
Route cable through
centre hole, then push
cable into bottom hole.
E
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
inished and make
sure the latch bolt
is fully extended.
actual
size
U
U
(2x)
bottom
hole
Once the door handing process
is complete, the touchscreen
will indicate success or failure:
Success: Failure:
lashing checkmark lashing
symbol and single
"X" pattern
column of digits
