Weiser HALO Installation And User Manual

67611-001
Rev 01
GED2500
Installation and User Guide
Required tools
Ruler Phillips head screwdriver
Additional Tools (depending on application)
Hammer Wood block Chisel
Prepare the door and check dimensions
1
A Make sure your door is compatible. If you have a standard deadbolt mounted
separately from the handle below it, your door is compatible.
Compatible
Measure to confirm that the hole in the door is either
C
2-1/8" (54 mm) or 1-1/2" (38 mm).
Note: Additional door
2-1/8"
preparation may be
54 mm
required for doors with
1-1/2" (38 mm) holes.
or
Consult the deadbolt
drilling instructions at
1-1/2"
weiserlock.com/doorprep
38 mm
2
Install the latch and strike
A
Is the door edge chiseled?
YES
or
chiseled
Use latch "A". If the
latch bolt is not already
extended, extend the
latch bolt as shown.
A
Weiser
1-800-501-9471
www.weiserlock.com
Not Compatible Not Compatible
Rim Mortise
Lock Lock
Measure to confirm that the backset is
D
either 2-3/8" or 2-3/4" (60 or 70 mm).
2-3/8" or 2-3/4"
60 or 70 mm
(2x)
For
Latch / Strike
Bag
03809
B
Hold the latch in front of the door hole, with the latch
face flush against the door edge.
NO
not
chiseled
Use latch "B". If the
latch bolt is not already
extended, extend the
latch bolt as shown.
C
Is the D-shaped hole centered in the door hole?
B
D-shaped hole
No adjustment is required.
Proceed to next step.
Parts List
Mounting Adapter
Plate Ring
Keys
Batteries
Latch A
Latch B
Not Compatible
Integrated
Interior
Measure to confirm that the hole
E
in the door edge is 1" (25 mm).
b a
c k
s e
t
(2x)
actual size 46780
A
B
YES NO
or
D-shaped hole
Rotate latch face as
shown to extend latch.
A
B
1 / 4
Exterior Assembly Interior Assembly
For Latch / Strike For Lock
Strike 03809
SmartKey
46780 49191
If drilling a new door, use the supplied template and the complete
door drilling instructions available at weiserlock.com/doorprep
B
Remove your existing deadbolt
from your door.
Measure to confirm that the door is between
F
1-3/8" and 2" (35 mm and 51 mm) thick.
1"
25 mm
(2x) (2x)
D
Which latch are you installing?
Latch "A"
or
UP is
on top.
or
A
or
03809*
(2x)
*Use longer
screws if
holes are
worn out.
E
Install the strike on the door frame.
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
Longer screws
install closest to
the door jamb.
46780
(4x)
48654
Tool
64109 68611
1-3/8" –2"
35 – 51 mm
actual size
Latch "B"
B
UP is
on top.
wood
block
door frame
