- Page 1 Upright Extractor OPERATORS MANUAL AND PARTS LIST Model PFX1300 SERIES WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL COMPLETELY BEFORE OPERATING THIS EQUIPMENT. X8498...
-
Page 2: Important Safety Precautions
12) DO NOT use to pick up flammable or combustible liquids such as Powr-Flite. gasoline or use in areas where they may be present. DO NOT handle plug or appliance with wet hands. -
Page 3: Grounding Instructions
GROUNDING INSTRUCTIONS D A N G E R : Improper use of the grounding plug can result in a risk of electric shock. GROUNDING INSTRUCTIONS This extractor must be properly grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electrical current to reduce the risk of electric shock. This machine is equipped with 1 or 2 pigtail cords having an equipment-grounding conductor and grounding plug. - Page 4 General instructions for PFX1300 series Extractors Congratulations on your purchase of a Powr-Flite extractor. You are now equipped to handle any and all commercial carpet cleaning jobs. Your new extractor is outfitted with a 1750-watt in-line heater (PFX1300H, PFX1300HP & PFX1300HDX models).
-
Page 5: Maintenance
Maintenance 2. Always disconnect electric cable from electrical outlet before attempting to make any adjustments or repairs. To receive reliable service from this equipment, regular daily maintenance is a requirement. Fabric cleaning, both carpet 3. Never use this equipment as a toy. and upholstery, are very dirty environments for any equipment. -
Page 6: Storage Of Equipment
12. Do not operate if pigtails, hoses, etc. are cracked, frayed, 4. Do not use cleaning chemicals in this machine except leaking, or otherwise in need of repair. those recommended for steam-type extraction equipment. The use of any chemicals with abrasive additives voids the 13. - Page 7 MODEL PFX1300 SERIES CARPET EXTRACTOR PARTS PFX1300 motor assembly PFX1300 High Pressure Pump (14) ref# order description ref# order description PF1750 inline heaterfor PFX1300H, HP, HDX PT400 200 psi pumpfor PFX1300HP PX13 gasket, foam, 5.5" od x 1.75" PT403 400 psi pump for PFX1300HDX, DX PX98 mounting plate, motor/pump/htr J1003GC...
- Page 8 MODEL PFX1300 SERIES CARPET EXTRACTOR PARTS PFX1300 upper housing assembly ref# order description ref# order description PC38 connector double thread female PX87 switch, rocker, w/protective cover PX32 X8102 fitting, brass, close nipple, neon light with lens PX42 clamp 5/8" PX86 indicator light green PX85 fitting, 1/4"...
- Page 9 MODEL PFX1300 SERIES CARPET EXTRACTOR PARTS PFX1300 lower housing assembly ref# order description ref# order description PX31 X8248 float cage w/heavy ball nut, 5/16" lock w/nylon insert PX33 float tube, pfx1300/h/hp X8252S 5/16-18 x 1 hex flange lok scr PX46 nut, lock, die cast, 1-1/2"...
-
Page 10: Troubleshooting Information
Troubleshooting Information ELECTRICAL SYSTEM F o a m / d i r t ys o l u t i o n 1 .F o a mf r o mc a r p e tb y - 1 .U s ea d d i t i o n a l c o m i n go u to fv a c u u m p a s s i n gw a t e rs h u t o f f . -
Page 12: Warranty
1 year on pump, vac motor, and parts and workmanship. In case you as our customer, meet any trouble with your machine, contact your Powr-Flite representative who will be happy to be of service to you and will take care of the warranty settlement.
