IMPORTANT INFORMATION * KEEP FOR OPERATOR * IMPORTANT INFORMATION
OPERATOR MANUAL
Part Number 137920-Rev A.
DHS
MODEL:
Low Height Steam
Jacketed Kettle
[with Standard Electronic Ignition]
Self-Contained
Stainless Steel
Gas Heated
Floor Mounted
Tilting
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT USER SMELLS GAS. THIS
INFORMATION SHALL BE OBTAINED BY CONSULTING YOUR LOCAL GAS SUP-
PLIER. AS A MINIMUM, TURN OFF THE GAS AND CALL YOUR GAS COMPANY
AND YOUR AUTHORIZED SERVICE AGENT. EVACUATE ALL PERSONNEL
FROM THE AREA.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAIN-
TENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION,
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
FOR YOUR SAFETY
POST IN A PROMINENT LOCATION
WARNING
OPERATING
AND
MAINTENANCE
OM-DHS
DOMESTIC
INSTRUCTIONS
