Data stored reading
Screen 3 :
●
Irr : represents the averaged value over a minute with date and time indicated of irradiance.
E : represents the energetic exposure in Wh/m
and time displayed.
To facilitate evaluation data, user can choose the scanning pitch through the D ,
then through arrow keys <
and time.
Screen 4 :
●
This screen visualizes a daily graphic display of irradiance values from 0:00 am to 0:00 pm on a scale of
1300 W/m² maximum
Choice of the day is made through arrow keys <
The Val pictogram appears. Press Val key to change the graph and to visualize it.

Data transfer

Screen 5 ''Data transfer '' allows data transfer toward a computer trough USB cable.
DL 200 software have been previously loaded into the computer (see notice of
DL 200 Software ).
To access screen 5 from reading screen, press
transfer. Then press USB symbol.
Once the connection, computer detects SL200 instrument on the appropriate port.
The software allows only the transfer, the instrument is still pending.
It only indicates date and time (which can be updated through software DL200).
File Format :
File values adopt a text termination : txt, which is easily exploitable by a Excel
spreadsheet for example.
accumulated from the beginning of measurement until date
2
D for date
H for hour
M for minute
(decremented) and > (incremented) user displays the searched date
(decrements) and
to obtaining the screen data
H , M key :
> (increments).
Data transfer
---------------------------------------------------------------
Raw data from the collector
---------------------------------------------------------------
Contents the 08/07/2008 at 18:31:52
---------------------------------------------------------------
08/06/2008,11:10:00,beginning
13/06/2008,13:09:00,end
08/06/2008,11:10:00,0007
08/06/2008,11:11:00,0019
08/06/2008,11:12:00,0021
08/06/2008,11:13:00,0023
08/06/2008,11:14:00,0025
08/06/2008,11:15:00,0025
Stored data
Graphic
Data transfer
SL N°9999
Data file text format
