III – Operating principle

Keyboard presentation

When being switched on, "measurement screen" is displayed. From this
screen, the operator has access to three others screens by pressing
on keyboard; return to measurement screen is obtained by
activating .
Function keys
Directly associated to text displayed shown above on
display, they allow measurement setting.
Key "leaves current screen"
Screen key
From measurement screens, give access to other screens
On/Off key
Instrument offers 3 groups of screens
1- Screens during measurement
Irradiance
Min./Max value
3- Setting screens
Brightness
Irradiation, average, accumulated energy, Irradiation, average, accumulated energy,
Min./Max instantaneous irradiation Min./Max instantaneous irradiation
Calibration
2- Reading screens after measurement
Min./Max instantaneous irradiation, reading of
About
Irradiation, average, accumulated energy,
memory and graphic display
