VII – Operating information

Over-range

Although it is quite impossible , in very special conditions of reflections concentrated to the
sensor, a pictogram of exceeded range appears
It comes for an irradiance higher to 1300 W/m

Sensor default

In case of a defective sensor (sensor unplugged) during the measurement, symbols
and disappear after its proper connection.
During the dysfunction sequence :
The chronometer still running correctly, it indicates to the operator the real duration of measurement
containing the time of sensor default.
Max. min., M. irradiation values are false. Only the energetic exposure is exploitable on the duration of
running without sensor default detected by the instrument.
To remind the operator this default and to keep it into consideration in
exploitation of results, a pictogram is at the top of the screen for the measure. It
is also displayed after the measurement.
Power source
When the instrument is equipped with alkaline batteries, it can operate for 72 hours minimum. A symbol informs the user
about electric power remaining. If battery is low, less than 1 bar on the pictogram, the instrument stops measuring, save
current measurement and switches off.
VIII – Maintenance

Servicing

The SL 200 instrument conception allows a reduce maintenance which consists in changing batteries and cleaning the sensor with a cloth
slightly dampened.

Clock

SL200 instrument has a permanent clock powered by an internal battery that is recharged when the device is switched on. In case of non-
use of the device, the battery will allow the running of the clock for 6 months.
After 6 months or at the start of the device, if it is displayed a wrong time (eg: 00:00), it means that it is necessary to recharge battery.
Switching SL200 instrument for about two hours allows its recharge.
Important : The correct resetting of the clock is made through a computer and the DL 200 software (cf. instructions for use of DL 200
software).
.
. The maximum value will indicate 1301 W/m².
2
* * *
appear
10
Overrange
Sensor default
