Page 1: User Manual
User Manual 1/3” HD-TVI, Day&Night, 12VDC, Infrared, IP-66 TVB-920F36IR TVB-980V2812IR TVD-920F36IR TVD-980V2812IR... - Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning with an arrowhead symbol, within an equilateral triangle is intended to alert the users to the presence of un-insulated “dangerous voltage”...
-
Page 3: Specifications
General Features • HD-TVI Technology • 1/3” CMOS Sony • Up to 500 meters • 3D DNR • BNC Video Output • Standard 12VDC Operation • IR LED for Night Vision • True Day/Night ICR Specifications General Model 720p 1080p IR LED 24/ 36pcs IR LED ( Model Dependant) Resolution... -
Page 4: Parts Supplied
TVB-920F36IR / TVB-980V2812IR Parts supplied Installation Locking Screw Rotation lock... - Page 5 1. Remove sun shield from camera to aid simpler installation (optional requirement). 2. Use drill template (D) as to guide to drill and attach camera to surface as required. Holes on bracket are 120 degree apart, so three holes are required. 3.
- Page 6 TVD-920F36IR / TVD-980V2812IR Parts supplied Installation Ceiling OPEN CLOSE VIDEO Pan 360° 12VDC Three axis rotate Adjust wrench Focus adjustment Zoom adjustment 1. Use the base as drill template. (Left is vari-focal model right fixed lens model)
- Page 7 2. Once base is firmly drilled into place, re-assemble parts. 3. Attach power and video. Make sure power + and - are correct 4. Position camera to suite make tight using the ring 5. Adjust the zoom & focus using the tool provided (Vari-Focal models) 6.
-
Page 8: Osd Control
OSD Control SET: Push [ SET ] to enter Main Menu UP/DOWN: [ UP ] or [ DOWN ] for move up and down. LEFT/RIGH T: [ LEFT ] or [ RIGHT ] for modifying the menu parameters. Please press down the set key for about 3 seconds and then release, can switch cycle simulation 720p and HD-TVI image signal output. -
Page 9: Video Settings
DAY / NIGHT • INTERNAL: Select this, the camera will show color image in high lux and will auto change intoblack/white image in low lux. Color: select this menu to show color image. Black/White select this menu to show black/white image. •... -
Page 10: Video Standard
• WDR: choose the setting for WDR in accordance with the lighting condition set hingh in strong ling ting contrast to realize higher quality image. • IRIS MANUAL: Please choose‘MANUAL’when use manual iris lens for the camera; • AUTO: Please choose‘AUTO’when use Auto iris lens for the camera. •... -
Page 11: Load Default
LANGUAGE • LANGUAGE: English, Chinese, Italian, French, Russian LOAD DEFAULT • LOAD DEFAULT: Restore the factory settings. SOFT VERSION • SOFT VERSION: SAVE / EXIT • SAVE / EXIT: After saving preferences to exit. EXIT • EXIT: Don’t save parameters exit. - Page 12 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
