- Page 1 HM-1404 MFFD/MFFE/MFI series MEMS Mass Flow Meters SIARGO MEMS FLOW SENSING PRODUCTS User Manual © 2013 Siargo Ltd. Länna, S-142 50 SKOGÅS Ordertel 08-771 00 04 Växel 08-771 02 20 Email info@hemomatik.se Stockholm, Sweden Orderfax 08-771 62 00 Teknisk 08-771 35 80...
- Page 2 Santa Clara, CA 95054 Tel: +1(408)969.0368 Email: info@siargo.com © Copyright 2013 by Siargo Ltd. Siargo Ltd. and its subsidiaries reserve the rights to change the specifications and/or descriptions without prior notice. For further information and updates, please visit: www.Siargo.com Länna, S-142 50 SKOGÅS Ordertel 08-771 00 04 Växel...
-
Page 3: Introduction
Do not use this product in any corrosive gas environment. Observe all requirements in accordance with the product specifications. Only qualified personnel from Siargo or a person who is accredited by Siargo can perform troubleshooting or service to the product. -
Page 4: Table Of Contents
MEMS Mass Flow Meter User Manual Contents Introduction 1 Usage and Safety 2 Overview 2.1 Siargo's MEMS Thermal Mass Flow Sensor Technology 2.2 Siargo's MEMS Thermal Mass Flow Meter 3 Working Principle 3.1 Working Principle 3.2 Volume Flow vs. Mass Flow 4 Product Model Selections 4.1 In-line Meters... -
Page 5: Usage And Safety
The specially designed circuitry provides amplification as well as small signal processing capability. Siargo's flow sensors utilize the thermal mass flow technology using energy balance design. Unlike the other MEMS flow sensing technologies, Siargo's flow sensors have multiple sensors integrated on a single silicon chip. -
Page 6: Working Principle
3. Working Principle 3.1 Working Principle Siargo's proprietary MEMS flow meters utilize the insertion sensing approach that can measure gas flows in a large pipe. The MEMS flow sensor integrates a micro heater, local temperature sensors and environmental temperature sensors onto a single package. At the no flow, a stable temperature field (distribution) around the micro heater is maintained. -
Page 7: Product Model Selections
4.1 In-line Meters/MFFD and MFFE series Gas (A - air; C - CO ; N - N ; O - O ; R - Ar; for other gases, please contact Siargo.) Output ( N- No output; A-4~20mA; B-RS485; D-pulse / 0 ~ 5 V; Options : B, AB, BD, ABD for external power model;... -
Page 8: Product Configuration
The configuration is illustrated in Fig. 5-1: Label User Interface LCD Display Smart Control Circuit Flow Pipe Flow Direction Connector (Flange or NPT) Fig. 5-1 5.2 Insertion Meters/MFI series Label User Interface LCD Display Smart Control Circuit Flow Direction Sensor Probe Valve Sensor Fig. 5-2 www.Siargo.com... -
Page 9: Product Specifications
DN (mm) Standards MF25 4 -φ14 MF32 4 -φ18 4-φ18 MF40 MF50 4-φ18 GB/T-9116.1-2000 MF65 8-φ18 MF80 8-φ18 MF100 8-φ18 MF25 CANSIB1.20.1NPT MF32 MF40 BSPT:ISO7/1 MF50 6.2 Physical Dimensions of Insertion Meters/MFI series Model MFI-1 MFI-2 MFI-3 Fig. 6-2 www.Siargo.com... -
Page 10: Flow Range Of In-Line Meters
100000 MFI-2 Ball valve=15 276+ H 130000 289+ H 160000 1000 1100 302+ H 200000 1200 329+ H 230000 1300 343+ H 270000 400;D=19; MFI-3 1400 356+ H 320000 Ball valve=20 1500 369+ H 360000 1600 382+ H 400000 www.Siargo.com... -
Page 11: Environmental Conditions
(3) Turn-Down Ratio: > 100:1 (4) Working Pressure: 1.5MPa (4) Pressure Loss: < 500 Pa (at max. flow) (5) Calibration: Air (20 C, 101.325kPa) (6) Protection: IP66 (7) Hazard Proof In-line meters: Ex d IIC T4 Insertion meters: n/a www.Siargo.com... -
Page 12: Installation
(2) Connect the cable of the meter (see Fig. 7-1). DC+, 12-24Vdc supply Black Black Power ground Green Brown Green RS485A Blue Purple Brown RS485B Orange Blue LOOP+ (4-20mA output) White Purple LOOP- (4-20mA GND) Orange Pulse output White Pulse GND Fig. 7-1 www.Siargo.com... - Page 13 (5) Once the above steps have been performed and no errors are found, it indicates that the meter is working properly. Then power off the meter by disconnecting the DC cable from the DC outlet, and it is ready to be installed onto the pipeline. (For battery powered meter, this step can be skipped) www.Siargo.com...
-
Page 14: Installation Procedure Of In-Line Meters
(3). Attach (by wielding for stainless steel pipeline) the base onto the flow channel, making the hole on the base align perfectly to that on the flow channel. (4). Place the O-ring or seal gasket on the base. Gasket O-ring Sealer Valve Connector Base Fig. 7-5 Detailed guidance for installation www.Siargo.com... - Page 15 Use of the “Sensor adjustment assistance tool kit” may help for a faster sensor alignment. For further information, please contact manufacturer. Probe base Installation base Fasten screw Sensor adjustment +3° assistance tool Flow direction -3° Fig. 7-8 Adjustment of the sensor Fig. 7-9 www.Siargo.com...
-
Page 16: Power Up
(6) Near the flow meter site, there should be neither any strong external magnetic field nor any strong mechanical vibration. (7) The gas medium should not have strong flow instability. The operation of the valves should be slowly. It is prohibited to close/open valves abruptly to create extreme pressure pulses. www.Siargo.com... -
Page 17: Display And Functions
Fig. 8-1 8.2 Access Points and User Interface Siargo's proprietary flow meter utilizes the insertion approach that can measure gas flows in large pipes. All access points and user interface are through the cable provided. 8.3 Real time display of both flow rate and accumulated volume... -
Page 18: Rs485 Data Communication Protocole
Then the meter will be at Local display mode at which the data will not be sent via RS485 by the meter. Protocol B Protocol B is based on the standard Modbus communication protocol. It supports either single meter communication or multi-meter networking. For detailed information, please contact the manufacturer. www.Siargo.com... -
Page 19: 20Ma Connection
8.8 Buttons Description Buttons Selection/confirmation of a setting Scroll up the setup menu SHIFT SHIFT Shift to next item or next bit Fig. 8-5 Please contact Siargo for the detailed buttons operations. www.Siargo.com... -
Page 20: Safety And Maintenance
Siargo Ltd. or any of its employees and subsidiaries shall not be held liable and indemnified against consequences due to such circumstances via improper use of the product. -
Page 21: Warranty
Siargo more than 365 days after a cause of action has accrued. The products returned under warranty to Siargo shall be at user or purchaser's risk of loss, and will be returned, if at all, at Siargo’s risk of loss. -
Page 22: Storage
Labels such as “handle with care”, “avoid collision” should be applied or otherwise clearly marked. Länna, S-142 50 SKOGÅS Ordertel 08-771 00 04 Växel 08-771 02 20 Email info@hemomatik.se Stockholm, Sweden Orderfax 08-771 62 00 Teknisk 08-771 35 80 Internet www.hemomatik.se www.Siargo.com...
