Chapter 2 : Overview
Test Leads, Connections, and Data Ports
The top of the EXP has two connectors for test cables:
RJ45 connector (Accessores Port) wth a
release lever for accessory test cable.
6-pn connector, wth a lockng rng, for the
battery test leads.
In addton, the top-left corner of the EXP has two IR data
ports:
Temperature measurement sensor.
Data transmtter, whch transmts test results to
an IR prnter
Standard and optonal test cables nclude:
Heavy duty battery test cable
(15-foot)
Amp clamp
DMM (Dgtal Multmeter)
cable
Banana Jack adapter
and probes
6-pin RJ45
