4.4

Unity Tab Menus

The Unity Tab shows the overall event status of the equipment and communication interface. It
contains logs of third party information, communications settings, third party protocol settings and
system status information as detailed below.
Table 4 Unity Tab menus
Unity Tab Menus
Active Events
Downloads
Configuration
Protocols
Status
™
LIFE device identity changed-LIFE
Duplicate Emerson Protocol MSTP Node ID
Support
Generate and download diagnostic file
NOTE
The card may be reset to factory defaults manually by briefly pressing the reset button five
times within 10 seconds.
Do not hold the reset button too long: Pressing the reset button and holding it for 5 seconds will
restart the card without resetting it to factory defaults.
To perform either function, insert a straightened paper clip into the small hole on the front of
the card (see Figure 1 for the Reset Button's location).
Agent (or Unity Card) Logs
Event Logs
Data Logs
Other files
System
User Settings
Network Settings
Web Server Settings
Emerson Protocol
Messaging Settings
Modbus
BACnet
YDN23
System Status
System Restart Required
™
needs to
be reconfigured
RS-485 Port Conflict
Duplicate BACnet MSTP Node ID
Agent time and Date
Agent Model
Agent App Firmware Version
Agent App Firmware Label
Agent Boot Firmware Version
Agent Boot Firmware Label
Agent Serial Number
Agent Manufacture Date
Agent Hardware Version
GDD Version
FDM Version
Product Sequence ID
Restart Card
Reset Card to Factory Defaults
(see Note below)
Firmware Update
Active Networking
Liebert IntelliSlot Unity Card Web Page Layout
Description
Displays the current event activity
Downloading files to text-accessible, comma-
delimited or tab-delimited files ease
troubleshooting.
Displays information about the system setup,
access, network connections, Emerson
Protocol settings and whether e-mail and
LIFE SMS messaging are enabled
Lists information and settings related to
available third-party protocols employed to
SNMP monitor equipment.
Shows the overall condition of the system
and whether a restart is needed to activate
configuration changes; restart is performed
only from the Support Folder
Shows information needed for maintenance
or troubleshooting and shortcuts to reboot
the card, reset the Liebert IntelliSlot Unity
card to its factory defaults and to update the
card's firmware.
25
See Details:
page 27
page 27
page 27
page 34
page 42
page 43
(Firmware
Update also
on page 46)
® ®
Liebert IntelliSlot Unity
™
Card
