Function
µA AC (EX363 only)
LCD Displays '0' counts when the reading < 10 counts
Input Impedance: 3kΩ approx.
Frequency Response: 45~500Hz (sine wave)
Over load protection: 1000V AC/DC
AC Current (EX365)
In 6A Range, the LCD displays 0 counts when the reading < 20 counts.
In10A Range, the LCD displays 0 counts when the reading < 10 counts.
Maximum measurement time: >5A for max. 3 minutes with at least 20 minutes rest time.
>10A for max. 30 seconds with at least 10 minutes rest time.
Frequency Response : 45 ~ 500Hz (Sine Wave)
Overload Protection : AC/DC 11A
DC Current (EX365)
Maximum measurement time : >5A for max. 3 minutes with at least 20 minutes rest time.
>10A for max. 30 seconds with at least 10 minutes rest time.
Overload Protection : AC/DC 11A
Resistance
Overload Protection: 1000V AC/DC
Note that digits may fluctuate ±50 digits when measuring above 10.00M
Continuity
Continuity: Built‐in beeper sounds when measured resistance is less than 20Ω. Beeper turns off when
measured resistance goes above 200Ω
Continuity beeper frequency tone: 2KHz; Response Time: < 500μsec.; Overload Protection: AC/DC 1000V
Diode
Open Circuit Voltage : Approx. 1.8V; Overload Protection : AC/DC 1000V
Capacitance
Overload Protection: 1000V AC/DC
Range Resolution Accuracy (of reading)
600.0 µA
6.000 A
10.00 A
6.000 A
10.00 A
600.0 Ω
6.000k Ω 0.001k Ω
60.00k Ω 0.01k Ω
600.0k Ω
6.000M Ω 0.001M Ω
40.00M Ω 0.01M Ω
600.0 Ω
1.550V
1.000 µF 0.001 µF
10.00 µF
100.0 µF
1.000 mF 0.001 mF
10.00 mF 0.01 mF
0.1uA ± (1.5% + 3 digits)
0.001
± (1.5% + 3 digits)
0.01
0.001
± (1.0% + 3 digits)
0.01
0.1 Ω ± (0.9% + 5 digits)
± (0.9% + 2 digits)
± (0.9% + 2 digits)
± (0.9% + 2 digits)
0.1k Ω
± (0.9% + 2 digits)
± (1.5% + 5 digits)
± (0.9% + 5 digits)
0.1 Ω
± (0.9% + 2 digits)
0.001V
± (1.9% + 5 digits)
0.01 µF
0.1 µF
± (1.9% + 2 digits)
23
'OL' Reading
660.0µA
6.600A
20.00A
6.600A
20.00A
660.0 Ω
6.600 kΩ
66.00 kΩ
660.0 kΩ
6.600 MΩ
44.00 MΩ
660.0 Ω
n/a
1.100 µF
11.00 µF
110.0 µF
1.100 mF
11.00 mF
EX36x‐en‐GB_V1.6 1/17
