Summary of Contents for Briteq BT-STROBE 1500
-
Page 3: Before Use
ENGLISH USER MANUAL OPERATION MANUAL ® Thank you for buying this BRITEQ product. To take full advantage of all possibilities and for your own safety, please read these operating instructions very carefully before you start using this unit. FEATURES This unit is radio-interference suppressed. This product meets the requirements of the current European and national guidelines. -
Page 4: Safety Instructions
• Always use an appropriate and certified safety cable when installing the unit. • In order to prevent electric shock, do not open the cover. Apart from the lamp and mains fuse there are no user serviceable parts inside. BRITEQ ® BT-STROBE 1500... -
Page 5: Lamp Replacement
• To avoid burned wires: make sure that the lamp wires are as far as possible from the lamp glass. • Connect the lamp wires to the screw terminals • Close the unit again and fasten the 2 screws marked “*” BRITEQ ® BT-STROBE 1500... -
Page 6: Overhead Rigging
DMX mode: Put DIP-switches (8) in “ON” position according the desired DMX-address (see also : [DIPSWITCH SETTINGS] below). The BT-STROBE1500 can now be controlled by any DMX controller or by ® the BRITEQ BT-STR4 strobe controller. BRITEQ ® BT-STROBE 1500... -
Page 7: Electrical Installation + Addressing
• Connect the device to the mains • Set the desired DMX-address on the strobes. • Now you can use the BT-STR4 remote to control the strobes, see user manual from the BT-STR4 for further instructions. BRITEQ ® BT-STROBE 1500... -
Page 8: Maintenance
• Connect the CA-8 remote to the 6,3mm jack connector (4) on the BT-Strobe 1500 (5) • Connect the BT-Strobe 1500 to the mains • Set DIP-switch 1 to ON • Now you can use the CA-8 remote to control the strobe. -
Page 9: Specifications
Lamp: Xenon 1500W Size: 458 x 147 x 116 mm Weight: 3,58 kg Every information is subject to change without prior notice You can download the latest version of this user manual on our website: www.briteq-lighting.com BRITEQ ® BT-STROBE 1500...
