Low Battery Alarm
When the transmitter in low battery, the transmitter will beep to remind the user to
land the drone to replace the batteries as soon as possible. Or the drone may out
of control.
When the drone in low battery, the transmitter will beep constantly to remind the
user to land the drone as soon as possible. The flip function will turn off
automatically when the drone in low battery.
Out of Range Alarm
When the drone flying out of the max remote control distance, the transmitter will
beep to alarm the user to fly back the drone immediately. Or the drone may out of
control and fly away.

Propeller Installation Diagram

1. To remove the propeller, pull up the propeller and remove
it from the motor axis as Picture 13.
2. To install the propeller, align the propeller hole to the motor
axis, press the propeller to the motor axis. Make sure the
propeller is perfect match with the motor axis as Picture 14.
Tip: please use a new A Propeller to replace the damaged
A Propeller, and B Propeller to replace the damaged B
Propeller.
Additional Instruction of Receiving Board
Plug the right-front #1 red plug (red and blue wire) into #1 red port.
Plug the right #2 white plug (white and black wire) into #2 white port.
Plug the right-rear #3 red plug (red and blue wire) into #3 red port.
Plug the left-rear #4 white plug (white and black wire) into #4 white port.
Plug the left #5 red plug (red and blue wire) into #5 red port.
Plug the left-front #6 white plug (white and black wire) into #6 white port.
5

To know your APP

Download and Install the APP: Flyingsee
The APP is suitable for mobile phone with iOS and Android system,
please download from the mobile phone software store:
1. For mobile phone with iOS system, please search Flyingsee in APP Store.
6 1
6
1
5
2 2
3
4
4 3
5
15
Picture 13
Picture 14
6
1
2
4 3
