Specifications - Icom iGM1600 Instruction Manual

11

SPECIFICATIONS

GENERAL
• Frequency coverage
TX/RX
• Mode
• Channel spacing
• Power supply requirement
• Current drain (at 7.5 V DC)
• Useable temperature range
• Frequency stability
• Antenna impedance
• Dimensions
(Projections not included)
• Weight (with BP-224)
TRANSMITTER
• Output power (at 7.5 V DC)
• Modulation system
• Microphone impedance
• Max. frequency deviation
• Adjacent channel power
• Spurious emissions
32
: 156.300–156.875 MHz
: 16K0G3E
: 25 kHz
: BP-234 or BP-224
: TX High (2 W) 1.0 A typical
Max. audio 200 mA typical
Power save 20 mA typical
: –20°C to +60°C; –4°F to +140°F
: ±5 ppm
(–20°C to +60°C;
–22°F to +140°F)
: 50 Ω
: 65(W) × 145(H) × 44(D) mm
(W) × 5 (H) × 1
2 ⁄ ⁄ ⁄ (D) inch
9 23 3
16 32 4
: Approx. 385 g (13.6 oz)
: 2 W (Hi) and 1 W (Low)
: Variable reactance frequency
modulation
: 2 kΩ
: ±5 kHz
: 70 dB
: Less than –70 dBc typical
RECEIVER
• Receive system
• Sensitivity (12 dB SINAD)
• Squelch sensitivity
• Intermodulation rejection ratio
• Spurious response rejection ratio
• Adjacent channel selectivity
• Audio output power
All stated specifications are subject to change without notice or
obligation.
: Double-conversion
superheterodyne
: 0.25 µV typical
: Less than 0.35 µV typical
(at threshold)
: 70 dB typical
: 70 dB typical
: 70 dB typical
: 0.35 W typical at 10% distor-
tion with an 8 Ω load
