Icom iGM1600 Instruction Manual page 26

TROUBLESHOOTING AND SURVIVAL CHANNELS
• TROUBLESHOOTING
PROBLEM
The transceiver does • The battery is exhausted.
not turn ON. • Bad connection to the battery pack.
No sound from the • Squelch level is too deep.
speaker. • Volume level is too low.
• Speaker has been exposed to water.
• Water has entered to [SP MIC] connector.
Transmitting is impos- • Some channels are for low power or re-
sible, or high power ceive only.
can not be selected. • The battery is exhausted.
• The battery is over charged.
• The output power is set to low.
The displayed channel • Lock function is activated.
cannot be changed.
No beeps. • Beep tones are turned OFF.
Self check error. • The temperature is outside of –35°C to
(Temperature) +80°C; –31°F to +173°F (approx.).
Self check error. • The connected battery pack's voltage is
more than 11 V.
(Battery voltage)
• SURVIVAL CHANNELS
CH TX/RX CH TX/RX
06 156.300 08 156.400
15* 156.750 16 156.800 17* 156.850
73 156.675 74 156.725
POSSIBLE CAUSE
CH TX/RX CH TX/RX
09 156.450 10 156.500
67 156.375
77 156.875
SOLUTION
• Recharge the battery pack.
• Check the connection to the transceiver.
• Set squelch to the threshold point.
• Rotate [VOL] to set a suitable level.
• Drain water from the speaker.
• Dry [SP MIC] connector.
• Change channels.
• Recharge the battery pack.
• Verify the battery voltage is correct.
• Push [Hi/Lo• ] to select high power.
• Push [Hi/Lo• ] for 1 sec. to cancel the
function.
• Set the beep tones to ON (Fix Beep/User
Beep) on the SET mode.
• Leave the transceiver at room temperature
for a while. Turn the power ON to check if the
internal temperature has returned to normal.
• Verify the battery voltage is correct.
CH TX/RX CH TX/RX
11 156.550 12 156.600
68 156.425 69 156.475
10
REF.
p. 22
p. 3
p. 9
p. 8
—
—
pgs. 8,
29
p. 22
—
p. 8
p. 10
p. 12
—
—
Unit: MHz
CH TX/RX CH TX/RX
13 156.650 14 156.700
71 156.575 72 156.625
*Low power only
9
10
31
