Introduction

Manage the Switch via the Device Manager
Web Interface
After you complete Express Setup, you can manage the switch by using the Device
Manager Web interface (supplied with the switch).
On all dialog boxes accessible from the Configure menu, when you click Submit,
changes are applied to the switch and stored on the CompactFlash card. If you
exit the Device Manager Web interface without clicking Submit, your changes are
not applied.
Topic
Access the Device Manager Web Interface
Front Panel View and Status Indicators
Assign Port Roles
Update Switch IP Information
Configure VLANs
Configure SNMP
Configure EtherChannels
Configure DHCP Persistence
Synchronize the Switch with Other Devices via PTP
Configure REP Segments
Configure IP Addresses
Enable Static Routing
Configure Port Mirroring
Dashboard Dialog Box
Port Status
Port Statistics
Alert Log
CIP Status
Upgrade the Switch Firmware
