44
Optional Equipment
7. Remove the cover plate and gasket over the low rate screw.
8. Remove the low rate screw and discard. Install the LP (propane) low rate screw (1.2mm – stamped
"120" near the base) – make sure it screws in all the way. Replace the cover plate and screws.
HINT: Unscrew the rate screw until it becomes loose. Then move it back and forth slightly
until it moves to the side. Then use needle-nose pliers to remove the rate screw.
© Travis Industries
1/4" Nutdriver
(
for qualified installers only)
4mm (5/32") Hex Wrench
LP Rate Screw
(1.2mm) – Stamped
"120" near the base
4151204
100-01430
