WARNING:
If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of
life.
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local
codes.
This appliance is only for use with the
type(s) of gas indicated on the rating plate.
A conversion kit is supplied with the
appliance.
Cypress
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
© Copyright 2010, T.I.
Owner's Manual
$10.00
100-01256_000
• Direct Vent Freestanding Stove
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Tested and Listed by
ANSI Z21.88 CSA 2.33
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
4101110
Mukilteo, WA 98275
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avalon Cypress
Summary of Contents for Avalon Cypress
- Page 1 This appliance is only for use with the type(s) of gas indicated on the rating plate. A conversion kit is supplied with the appliance. Cypress Owner’s Manual INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
-
Page 2: Introduction & Important Information
Introduction Introduction We welcome you as a new owner of a Cypress stove. In purchasing a Cypress you have joined the growing ranks of concerned individuals whose selection of an energy system reflects both a concern for the environment and aesthetics. The Cypress is one of the finest home heaters the world over. -
Page 3: Table Of Contents
Table of Contents Introduction Operation Introduction & Important Information ....2 Before You Begin ..........29 Location of Controls ..........29 Safety Precautions Starting the Stove for the First Time ....30 Safety Precautions ..........4 Turning the Stove On and Off ......30 Features &... -
Page 4: Safety Precautions
Safety Precautions • IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department •... -
Page 5: Travis Industries
Safety Precautions • Do not place clothing or • Light the heater using the other flammable items on or built-in igniter. Do not use near the heater. Because matches or any other this heater can be controlled external device to light your by a thermostat there is a heater. -
Page 6: Features
Specifications Features: Installation Options: Works During Power Outages (battery backup system) Freestanding Stove High Efficiency Horizontal or Vertical Vent Convenient Operating Controls Residential or Mobile Home Variable-Rate Heat Output Straight or Corner Placement Accent Light Bedroom Approved Heating Specifications: Approximate Heating Capacity (in square feet)* ... 1,200 – 2,000 with Blower, 800 – 1,600 Without Maximum Input ....................40,000 BTU’s •... -
Page 7: Installation
Installation (for qualified installers only) Installation Warnings: Failure to follow all of the requirements may result in property damage, bodily injury, or even death. This heater must be installed by a qualified installer who has gone through a training program for the installation of direct vent gas appliances. -
Page 8: Packing List
Installation (for qualified installers only) Packing List Additional Items Required • Propane Conversion Kit • Vent (see “Venting Requirements” for details) • Touch-Up Paint • Gas Line Equipment (shutoff valve, pipe, etc.) • ½” FPT to 3/8” Flare Fitting • Approved Travis Media (Logs 94500561, Driftwood •... -
Page 9: Stove Clearances
Installation (for qualified installers only) Stove Clearances Top Vent Straight Installations Top Vent Corner Installations With this clearance the top vent is centered 6-7/8" (175mm) from the back wall, 25-1/8" (638mm) from With this clearance, the vent is the side wall. centered 16-1/2"... - Page 10 Installation (for qualified installers only) Top to Rear Vent Modification NOTE: The rear vent parts are included in the Minimum Vent Kit “D” (sku 96200317). If using the rear vent configuration, make sure to review vent configuration before proceeding. © Travis Industries 4101110 100-01256_000...
-
Page 11: Mobile Home Requirements
Installation (for qualified installers only) Heater Placement Requirements • Heater must be installed on a level surface capable of supporting the heater and vent. • Due to the high temperature, the heater should be located out of traffic and away from furniture and draperies. -
Page 12: Optional Wall Switch Or Thermostat Installation
Installation (for qualified installers only) Optional Wall Switch or Thermostat Installation Do not connect 110-120 VAC to the gas control valve or wiring system of this stove. The switch must be installed by a qualified installer. This stove may be installed with an optional wall switch or thermostat. The thermostat (or on/off switch) wires will interrupt the burner circuit (see item “a”... -
Page 13: Gas Line Installation
Installation (for qualified installers only) Gas Line Installation The gas line must be installed in accordance with all local codes, if any; if not, follow current ANSI Z223.1 or NFPA 54 in the USA and the current CSA B149.1 in Canada. The heater and gas control valve must be disconnected from the gas supply piping during any pressure testing of that system at test pressures in excess of 1/2 psig (3.45 kPA). -
Page 14: Vent Requirements
Installation (for qualified installers only) Vent Requirements • The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent gas appliance must use it's own separate vent system. -
Page 15: Approved Vent Configurations
Installation (for qualified installers only) Approved Vent Configurations Exhaust Restrictor Position • An exhaust restrictor is built into the appliance to control the flow rate of exhaust gases. This ensures proper flames for the wide variety of vent configurations. Depending upon the vent configuration, you may be required to adjust the restrictor position. -
Page 16: Closing The Diffuser
Installation (for qualified installers only) Closing the Diffuser (for top vent configurations only) IMPORTANT NOTE: The diffuser can be easily closed with no vent in place. Consult the vent configuration charts to determine diffuser position. If the diffuser needs to be in the closed position, adjust the diffuser prior to installing vent. -
Page 17: Exhaust Restrictor Extender
Installation (for qualified installers only) Exhaust Restrictor Extender (for rear vent configurations only) • Follow the directions below to install the exhaust restrictor extender. Remove these two screws on the exhaust restrictor. Exhaust Restrictor Extender Plate (included in the rear vent kits) Use the screws to attach the extender to the exhaust restrictor. -
Page 18: Rear Vent Configuration With No Rise
Installation (for qualified installers only) Rear Vent Configuration with No Rise • Use the minimum vent kit “D” from Travis Industries (SKU 96200317). This kit contains the following components used to vent the stove through a typical exterior wall: -- Travis Thimble (unique to this stove) -- Wall Cover (Black) -- Pipe Section (3.9”) -- Pipe Section (6”) -
Page 19: Rear Vent Configuration With Horizontal Termination
Installation (for qualified installers only) Rear Vent Configuration with Horizontal Termination • Use the rear vent conversion from Travis Industries (SKU 94400998). • Use 8” Diameter Vent • Horizontal sections require a ¼” (6mm) rise every 12” (305mm) of travel. •... -
Page 20: Rear Vent Configuration With Vertical Termination
Installation (for qualified installers only) Rear Vent Configuration with Vertical Termination • Use the rear vent conversion from Travis Industries (SKU 94400998). • Use 8” Diameter Vent • Horizontal sections require a ¼” (6mm) rise every 12” (305mm) of 31' max (9.3m) 31' max (9.3m) travel. -
Page 21: Top Vent With Horizontal Termination
Installation (for qualified installers only) Top Vent Configuration with Vertical Termination • Use 6-5/8” Diameter Vent • Horizontal sections require a ¼” (6mm) rise every 12” (305mm) of travel. • A maximum of four (4) 45° or 90° elbows may be used. Of these elbows, only one (1) may be a horizontal elbow (see illustration). -
Page 22: Top Vent With Vertical Termination
Installation (for qualified installers only) Top Vent Configuration with Horizontal Termination • Use 6-5/8” Diameter Vent • Horizontal sections require a ¼” (6mm) rise every 12” (305mm) of travel. • A maximum of four (4) 45° or 90° elbows may be used. Of these elbows, only one (1) may be a horizontal elbow (see illustration). -
Page 23: Vent Termination Requirements
Installation (for qualified installers only) Vent Termination Requirements (see illustration below) Venting terminals shall not be recessed into a wall or siding. Minimum 9" (229mm) clearance from any door or window Roof Minimum 12" (305mm) above any grade, veranda, porch, deck or balcony Surface Minimum 12"... -
Page 24: Leak Test
Installation (for qualified installers only) Steps for Finalizing the Installation Remove the glass (see page 26). NOTE: If using propane (LP) convert the appliance prior to installing the logs, driftwood, or stone set. We recommend you purge the gas line at this time (with the glass removed). This allows gas to be detected once it enters the firebox, ensuring gas does not build up. -
Page 25: Air Shutter Adjustment (If Necessary)
Installation (for qualified installers only) Check the air shutter following the directions below. Air Shutter Adjustment Let the heater burn for fifteen minutes (make sure the media and glass are in place). The flames should be yellow with no sooting. Adjust the air shutter, if necessary, to achieve the correct looking flame. -
Page 26: Face And Glass Removal
Finalizing the Installation (for qualified installers only) Face and Glass Removal Make sure the gas control valve is “OFF” and the heater is cool prior to conducting service. Open the two latches holding the Phillips Screwdriver glass frame in place - follow the directions shown below Remove the two screws securing the stove top. - Page 27 Finalizing the Installation (for qualified installers only) Glass Frame Removal and Installation (continued) The latch can come loose from glass frame anchor. This occurs when it is turned 1/4 turn when it is disengaged. Follow the directions below to re-install the latch if it becomes loose.
-
Page 28: Media Installation (Log, Stone, Or Driftwood)
Finalizing the Installation (for qualified installers only) Media Installation (Log, Stone, or Driftwood) The logs are fragile, especially after being exposed to heat. • Make sure the gas control valve is “OFF” and the heater is cool prior to conducting service. •... -
Page 29: Travis Industries
Operation Before You Begin Warning: Read this entire manual before you use your new stove (especially the section "Safety Precautions" on pages 4 & 5). Failure to follow the instructions may result in property damage, bodily injury, or even death. Warning: Do not operate appliance with the glass front removed, cracked or broken. -
Page 30: Starting The Stove For The First Time
Operation Starting the Stove for the First Time • Burn the heater at a high setting with the blower off for an extended period (up to 48 hours). This will cure the painted surfaces. Fumes from the paint curing and oil burning off the steel will occur. This is normal. -
Page 31: Accent Light
Operation Accent Light This stove has a built-in accent light HIGH that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. ACCENT LIGHT Adjusting the Optional Blower Speed The blower helps transfer heat from the heater into the room. It will not turn on until the heater is up to temperature (approximately 15 minutes after starting). -
Page 32: Normal Operating Sounds
Operation Normal Operating Sounds Extinction Pops It is not unusual, especially on Propane The appliance may creak with change of (LP) appliances, to experience a "pop" temperature -- THIS IS NORMAL. when the burner is shut off. Blower Pilot Assembly This heater has an optional blower to push The pilot flame will make a clicking heated air into the room. -
Page 33: Maintenance
Maintenance (for qualified service personnel only) Maintaining Your Stove's Appearance Painted Surfaces • Painted surfaces should be cleaned with a duster. If scratches occur, lightly sand the area with fine sandpaper. Clean the area and, with the stove cool, apply one or two thin coats of stove paint to the area (mask the area to avoid overspray). -
Page 34: Accent Light Replacement
Maintenance (for qualified service personnel only) Accent Light Replacement An accent light is included in your stove to provide additional lighting. To replace the bulb, follow the directions below: • Disconnect stove from power. Shut off gas to the stove. Make sure the stove is cool before proceeding (15 minutes). -
Page 35: Yearly Service Procedure
Maintenance (for qualified service personnel only) Yearly Service Procedure • Failure to inspect and maintain the stove may lead to improper combustion and a potentially dangerous situation. We recommend the following procedures be done by a qualified technician. Turn the pilot flame to continuous. It should touch approximately 3/8" of the top of the flame sensor. If it does not, contact your dealer for service. -
Page 36: Troubleshooting Table
Maintenance (for qualified service personnel only) Troubleshooting Table Problem: Possible Cause: Don't Call for Service Until You: The ON/OFF switch is turned to "OFF" Turn the ON/OFF switch to "ON" Main Burners Will The remote control is not working correctly See the remote control instructions Not Start The thermostat is disconnected or set too low... -
Page 37: Wiring Diagram
Maintenance (for qualified service personnel only) Wiring Diagram Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Spark Rod Accent Pilot Light (s) Sensor Accent Light Rheostat Pilot Ground Optional... -
Page 38: Replacement Parts List
Maintenance (for qualified service personnel only) Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 39: Safety Label
Safety Label Safety Label The safety (listing) label is attached under the stove. A copy is shown below. © Travis Industries 4101110 100-01256_000... -
Page 40: Warranty
Limited Lifetime Warranty Register your TRAVIS INDUSTRIES, INC. Limited 7 Year Warranty online at traviswarranty.com, or complete the enclosed Warranty card and mail it within ten (10) days of the appliance purchase date to: TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this gas appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call. -
Page 41: Optional Equipment
Optional Equipment (for qualified installers only) LP Conversion Instructions WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions are not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life. - Page 42 Optional Equipment (for qualified installers only) 3 Grasp the burner with both hands and lift it straight up and out of the firebox. Discard the rear air deflector. 4 Discard the manifold cover (see below). © Travis Industries 4101110 100-01256_000...
- Page 43 Optional Equipment (for qualified installers only) 5 Install the LP (propane) orifices. Rear Burner Orifice Front Burner Orifice Thread Sealant 15/16" 24mm 1/2" Wrench Orifice ID ORIFICE SIZE (ID) Natural Gas LP (Propane) Front Burner Orifice #49 DMS #57 DMS Rear Burner Orifice #43 DMS #53 DMS...
- Page 44 Optional Equipment (for qualified installers only) 6 Install the LP (propane) manifold cover included in owner’s pack (see illustration below). 7 Remove the pilot orifice following the instructions below. Replace with the propane pilot orifice. Remove the orifice and replace with the LP orifice. Screw the Lift the pilot hood orifice all the way in and replace the pilot hood.
- Page 45 Optional Equipment (for qualified installers only) 9 Replace the regulator following the instructions included with the regulator kit. Remove and discard the screws (see “a” below) holding the stock regulator in place (see “b” below). Remove the stock regulator and gasket (see “c” below). Place the LP regulator in place, making sure the pre-fitted gasket (see”c”...
-
Page 46: Greensmart™ Remote Control Installation
Optional Equipment (for qualified installers only) GreenSmart™ Remote Control Installation Packing List • Transmitter • Receiver (with Cover Plate & Switch) • Fan Control Module • Velcro • LP or NG Stepper Motor (with screws and label - attaches to Valve) •... - Page 47 Optional Equipment (for qualified installers only) Overview The GreenSmart remote includes a new wiring harness that replaces the stock wiring harness. Before installing, familiarize yourself with the stock and updated wiring diagrams (see the illustrations on this page and and following page). Stock Wiring Diagram Spark Rod Accent...
- Page 48 Optional Equipment (for qualified installers only) GreenSmart Wiring Diagram Spark Rod Pilot Comfort Control Sensor Valve PILOT DIGITAL SENSOR FIREPLACE BURNER CONTROL SPARK ROD DIAGNOSTIC Pilot VALVE COMMAND POWER Ground GROUND BURNER CONTROL RECEIVER Orange Green Remote Yellow / Green Receiver IPI / CPI Blue...
- Page 49 Optional Equipment (for qualified installers only) Installation WARNING: Make sure power to the stove has been shut off prior to installation. NOTE: Refer to the wiring diagram on page 48 while making wiring harness connections. Loosen the bottom panel attachment screws with a ¼” open-end wrench (there are two on each side - see Figure 1).
- Page 50 Optional Equipment (for qualified installers only) Unplug the ac adapter from the power harness (see Figure 5). You can leave the ac adapter plugged into the wiring harness. Figure 5 Disconnect the molex connector leading to the gas control valve (see Figure 6). WARNING: The tabs on the gas control valve are fragile.
- Page 51 Optional Equipment (for qualified installers only) Disconnect the comfort control valve connection (see Figure 8). Disconnect the burner control connector from the fireplace burner control (see Figure 9). Figure 8 Figure 9 Disconnect the on/off switch wires (labeled ON/OFF - see Figure 10). Unscrew the on/off/battery plate from the control panel (see Figure 11).
- Page 52 Optional Equipment (for qualified installers only) Use the included torx wrench to remove the stock regulator (see Figure 14). The old regulator may be discarded. Figure 14 10 The stepper motor (adjustable regulator) has an installation sheet included with it – make sure to follow all of the directions.
- Page 53 Optional Equipment (for qualified installers only) 12 Attach the wiring harness to the burner control (see Figure 18). Attach the gas control valve molex connector (see Figure 19). Figure 18 Figure 19 13 Attach the blue and white wires to the IPI/CPI switch (see Figure 20). Connect the wiring harness to the stepper motor (see Figure 21).
- Page 54 Optional Equipment (for qualified installers only) 15 Place the fan controller on the bottom panel as shown in Figure 23. Make sure the control module is positioned with the power cord to the right and the module at the back edge of the bottom panel. Figure 23 16 Attach the power cord from the fan controller to the AC connection (see Figure 24).
- Page 55 Optional Equipment (for qualified installers only) 18 Attach the accent light power lead to the fan controller in the “AUX OUT” receptacle (see Figure 28). Figure 28 NOTE: If using the optional fan, you will want to disconnect its power lead and connect it to the extra power lead included with this kit, then connect it to the “FAN”...
- Page 56 Optional Equipment (for qualified installers only) 20 Attach the receiver to the control panel with the two #8 machine screws (Figure 31). Figure 31 21 Re-attach the bottom plate to stove, taking care to prevent any wiring from being pinched (see Figure 32).
- Page 57 Optional Equipment (for qualified installers only) 23 Place the receiver coverplate (and switch) over the receiver (see Figure 35) and attach with the two screws included with the receiver (see Figure 36) Figure 36 Figure 35 24 A wall mount is included with this kit for the remote. It may be mounted to the wall for easy access and storage.
-
