- Page 1 SUPERMARINE Spitfire MK IXc User Manual Wingspan : 1200mm Item No.: FLW203 1 ~ 12 中 13 ~ 24 E 25 ~ 42 MADE IN CHINA www.sz-freewing.com...
- Page 2 Air Intake Scoop. Main Landing Gear 2- Servo Introduction, Battery Installation 3- Power System/ Propeller/ ESC Installation 4- Motor Parameters/ Center of Gravity 5- Control Direction Setup 6- Dual Rates/ Installing optional plastic hinges Build Notes SpitfireMK.IXc ItemNo.:FLW203...
- Page 3 Freewing. Flightline brings to you the outstanding innovation, exquisite design, high quality, unbeatable value, and dependable performance you come to expect from Freewing. Thank you for purchasing the FlightLineRC 1200mm Spitfire Mk.
-
Page 4: Package List
Main wing Spinner & fixed part electronic parts servo equipment No electronic Pre-installed all Pre-installed Tail wing set Installed part & screw electronic parts equipment servo Foam parts Fiberglass tube & glue "Y" wire Manual Spitfire MK.IXc Item No.: FLW203... - Page 5 Step 4 Use 4pcs screws to fix the main wing. Note: There is EPO glue in the kit, please use it for assembly. For best results, glue should be spread evenly, then wait for 90 seconds before joining. SpitfireMK.IXc ItemNo.:FLW203...
- Page 6 A - Fiberglass tube Ø4mm×250mm B - Screws (KA 3× mm) 1. Referring to the above photo, install the left/right elevator on the tail of t he fuselage. 2.Turn the fuselage over, and use 4 screws to secure the elevator. SpitfireMK.IXc ItemNo.:FLW203...
- Page 7 Steering pushrod mounting hole Pushrod diameter : Ø 1.2mm 545mm (21-1/2") Rudder pushrod size Rudder pushrod mounting hole Pushrod diameter : Ø 1.2mm 68mm (2-4/5") Elevator pushrod mounting hole Elevator pushrod size Pushrod diameter : Ø 1.2mm 597mm (23-1/2") SpitfireMK.IXc ItemNo.:FLW203...
-
Page 8: Main Landing Gear Assembly
Follow the diagram to assemble/disassemble the landing gear. Accessories Main landing gear supporting rod Wheel (Ø65×16mm) Wheel locks (Ø5.5×Ø4.2mm) Jimi screw (M3×3mm) Main gear door Screw (PB2.3×4mm) Retract servo Jimi screw (M3×3mm) Screw (KA2.6×12mm) Landing gear strengthening plate Landing gear Landing gear mount SpitfireMK.IXc ItemNo.:FLW203... -
Page 9: Installing A Battery
Once the battery is connected and signal is confirmed, > Discharge rate of C make sure there is nothing in front of the airplane or within the diameter of the propeller to avoid accidents and injury. SpitfireMK.IXc ItemNo.:FLW203... -
Page 10: Power System Installation
You can contact our distributor to purchase its high power system. Installing the ESC Screw (PWA3×8mm 4pcs) Battery tray Tray holder Put the ESC under the battery tray There are specially designed ventilation ducts that will cool the electric equipment effectively. SpitfireMK.IXc ItemNo.:FLW203... -
Page 11: Motor Parameters
880RPM/V Motor shaft, X-fixed base Ø20 4-Ø2.6 Ø9.0 Ø6.0 4-Ø3.2 11.0 24.0 Unit: mm CG by moving the battery, you can also use an alternate material such as sticky backed lead weight to achieve the CG. 73mm (2-7/8") SpitfireMK.IXc ItemNo.:FLW203... - Page 12 After the build is complete with the propeller removed, power up the radio and connect a fully charged battery to the ESC. Use the radio to ensure proper control direction as shown in the diagrams below: SpitfireMK.IXc ItemNo.:FLW203...
- Page 13 Step three As shown in the diagram, apply glue to the other end of the hinge and attach it to control surface. SpitfireMK.IXc ItemNo.:FLW203...
- Page 14 Build Notes Hey guys! I've taken the time to check out both the build video and the Flight Video by Ryan Ramsay of Motion R/C as well as go through the posts on Hobby Squawk to try to gather any build/ flight tips that may help you get through both successfully, with a minimum of trouble.
- Page 15 Dongguan Freewing Electronic Technology Ltd HK Freewing Model International Limited Add.:FeiYi Building,face to Labor Bureau, Fumin Middle Road, Dalang Town, Dongguan City，Guangdong Province, China Web: http://www.sz-freewing.com Email:freewing@sz-freewing.com Tel: 86-769-82669669 Fax:86-769-82033233 东莞市飞翼 电子 科 技有 限 公 司 香 港 飞 翼 模 型 国 际 有 限 公 司 地址: 广...
