Port Mirroring Analyzers Feature Guide for EX9200 Switches
Mirroring All Employee Traffic to Multiple VLAN Member Interfaces for Remote Analysis
CLI Quick
Configuration
44
In this example:
Interfaces ge-0/0/0 and ge-0/0/1 are Layer 2 interfaces (both interfaces on the source
switch) that serve as connections for employee computers.
Interfaces ge-0/0/10 and ge-0/0/11 are Layer 2 interfaces that are connected to
different destination switches.
Interface ge-0/0/12 is a Layer 2 interface that connects the Destination 1 switch to the
remote monitoring station.
Interface ge-0/0/13 is a Layer 2 interface that connects the Destination 2 switch to
the remote monitoring station.
VLAN is configured on all switches in the topology to carry the mirrored
remote-analyzer
traffic.
To configure mirroring to multiple VLAN member interfaces for remote traffic analysis
for all incoming and outgoing employee traffic, perform these tasks:
To quickly configure mirroring for remote traffic analysis forincoming and outgoing
employee traffic, copy the following commands and paste them into the switchterminal
window:
In the source switchterminal window, copy and paste the following commands:
[edit]
set vlans remote-analyzer vlan-id 999
set interfaces ge-0/0/10 unit 0 family ethernet-switching interface-mode access
set interfaces ge-0/0/10 unit 0 family ethernet-switching vlan members 999
set interfaces ge-0/0/11 unit 0 family ethernet-switching interface-mode access
set interfaces ge-0/0/11 unit 0 family ethernet-switching vlan members 999
set forwarding-options analyzer employee-monitor input ingress interface ge-0/0/0.0
set forwarding-options analyzer employee-monitor input ingress interface ge-0/0/1.0
set forwarding-options analyzer employee-monitor input egress interface ge-0/0/0.0
set forwarding-options analyzer employee-monitor input egress interface ge-0/0/1.0
set forwarding-options analyzer employee-monitor output next-hop-group remote-analyzer-nhg
set forwarding-options next-hop-group remote-analyzer-nhg interface ge-0/0/10.0
set forwarding-options next-hop-group remote-analyzer-nhg interface ge-0/0/11.0
set forwarding-options next-hop-group remote-analyzer-nhg group-type layer-2
In the Destination 1 switchterminal window, copy and paste the following commands:
[edit]
set vlans remote-analyzer vlan-id 999
set interfaces ge-0/0/10 unit 0 family ethernet-switching interface-mode acess
set interfaces ge-0/0/12 unit 0 family ethernet-switching interface-mode access
set forwarding-options analyzer employee-monitor input ingress vlan remote-analyzer
set forwarding-options analyzer employee-monitor loss-priority high output interface
ge-0/0/12.0
In the Destination 2 switchterminal window, copy and paste the following commands:
[edit]
set vlans remote-analyzer vlan-id 999
set interfaces ge-0/0/11 unit 0 family ethernet-switching interface-mode access
set interfaces ge-0/0/13 unit 0 family ethernet-switching interface-mode access
set forwarding-options analyzer employee-monitor input ingress vlan remote-analyzer
