Chapter 3: Copy Packets to a VLAN or Bridge Domain for Remote Monitoring
user@device# set analyzer employee-monitor input maximum-packet-length 128
Bind the statistical analyzer to the FPC that contains the input interface.
[edit]
user@device# set chassis fpc 0 port-mirror-instance employee-monitor
On the destination network device, do the following:
2.
Configure the VLAN ID for the
[edit]
user@device# set vlans remote-analyzer vlan-id 999
Configure the interface on the destination switching device for access mode and
associate it with the
[edit interfaces]
user@device# set ge-0/0/10 unit 0 family ethernet-switching interface-mode
access
user@device# set ge-0/0/10 unit 0 family ethernet-switching vlan members 999
Configure the interface connected to the destination switching device for access
mode.
[edit interfaces]
user@device# set ge-0/0/5 unit 0 family ethernet-switching interface-mode
access
Configure the
employee-monitor
[edit forwarding-options]
user@device# set analyzer employee-monitor input ingress vlan remote-analyzer
user@device# set analyzer employee-monitor output interface ge-0/0/5.0
Specify mirroring parameters such as rate and the maximum packet length for
the
employee-monitor
[edit]
user@device# set forwarding-options analyzer employee-monitor input rate 2
user@device# set forwarding-options analyzer employee-monitor input
maximum-packet-length 128
Bind the
employee-monitor
[edit]
user@device# set chassis fpc 0 port-mirror-instance employee-monitor
Check the results of the configuration on the source switching device:
[edit]
user@device# show
forwarding-options {
analyzer employee-monitor {
input {
ingress {
interface ge-0/0/0.0;
interface ge-0/0/1.0;
}
egress {
remote-analyzer
VLAN.
remote-analyzer
analyzer.
analyzer.
analyzer to the FPC containing the input ports.
VLAN.
35
