Port Mirroring Analyzers Feature Guide for EX9200 Switches
Results
Verification
Purpose
22
MX Series
To configure
family bridge
or
access interface-mode trunk
[edit]
set interfaces ge-0/0/0 unit 0 family bridge interface-mode access vlan-id 99
set interfaces ge-0/0/1 unit 0 family bridge interface-mode access vlan-id 98
Configure each interface connected to employee computers as an input interface
2.
for the analyzer
employee-monitor
[edit forwarding-options]
set analyzer employee-monitor input ingress interface ge-0/0/0.0
set analyzer employee-monitor input ingress interface ge-0/0/1.0
Configure the output analyzer interface for the
3.
This will be the destination interface for the mirrored packets.
[edit forwarding-options]
set analyzer employee-monitor output interface ge-0/0/10.0
Check the results of the configuration.
[edit]
user@device# show forwarding-options
analyzer {
employee-monitor {
input {
ingress {
interface ge-0/0/0.0;
interface ge-0/0/1.0;
}
}
output {
interface ge-0/0/10.0;
}
}
}
Verifying That the Analyzer Has Been Correctly Created
Verify that the analyzer
employee-monitor
the appropriate input interfaces and the appropriate output interface.
on an interface, you need to configure
as well. You also must configure
.
employee-monitor
has been created on the switching device with
Copyright © 2016, Juniper Networks, Inc.
interface-mode
.
vlan-id
analyzer.
