Verification
Purpose
Action
Meaning
Related
Documentation
Example: Configuring Mirroring to Multiple Interfaces for Remote Monitoring of
Employee Resource Use on EX9200 Switches
Copyright © 2016, Juniper Networks, Inc.
Chapter 3: Copy Packets to a VLAN or Bridge Domain for Remote Monitoring
Verifying That the Analyzer Has Been Correctly Created
Verify that the analyzer named
the appropriate input interfaces and appropriate output interface.
To verify that the analyzer is configured as expected while monitoring all employee traffic
on the source switching device, run the
the source switching device. The following output is displayed for this configuration
example.
user@device> show forwarding-options analyzer
Analyzer name
Mirror rate
Maximum packet length
State
Ingress monitored interfaces
Ingress monitored interfaces
Egress monitored interfaces
Egress monitored interfaces
Output VLAN
This output shows that the
size of the original packet that were mirrored is 128, the state of the configuration is
which indicates proper state and that the analyzer is programmed, and the analyzer is
mirroring the traffic entering ge-0/0/0.0 and ge-0/0/1.0, and is sending the mirrored
traffic to the VLAN called remote-analyzer.
If the state of the output interface is
value of will be down and the analyzer will not be able to mirror traffic.
State
Example: Configuring Port Mirroring Analyzers for Local Monitoring of Employee
Resource Use on page 19
Example: Configuring Mirroring to Multiple Interfaces for Remote Monitoring of Employee
Resource Use on EX9200 Switches on page 41
Configuring Mirroring on EX9200 Switches to Analyze Traffic (CLI Procedure) on
page 13
Understanding Port Mirroring Analyzers on page 4
EX9200 switchesallow you to configure mirroring to send copies of packets to either a
local interface for local monitoring or to a VLAN for remote monitoring. You can use
mirroring to copy these packets:
Packets entering or exiting a port
has been created on the device with
employee-monitor
show forwarding-options analyzer
: employee-monitor
: 2
: 128
: up
: ge-0/0/0.0
: ge-0/0/1.0
: ge-0/0/0.0
: ge-0/0/1.0
: default-switch/remote-analyzer
instance has a ratio of 2, the maximum
employee-monitor
or if the output interface is not configured, the
down
command on
,
up
