Port Mirroring Analyzers Feature Guide for EX9200 Switches
Step-by-Step
Procedure
34
Copy and paste the following commands in the source switching device's terminal
window:
EX Series
[edit]
set vlans remote-analyzer vlan-id 999
set interfaces ge-0/0/10 unit 0 family ethernet-switching interface-mode access
set interfaces ge-0/0/10 unit 0 family ethernet-switching vlan members 999
set forwarding-options analyzer employee-monitor input ingress interface ge-0/0/0.0
set forwarding-options analyzer employee-monitor input ingress interface ge-0/0/1.0
set forwarding-options analyzer employee-monitor input egress interface ge-0/0/0.0
set forwarding-options analyzer employee-monitor input egress interface ge-0/0/1.0
set forwarding-options analyzer employee-monitor output vlan remote-analyzer
set forwarding-options analyzer employee-monitor input rate 2
set forwarding-options analyzer employee-monitor input maximum-packet-length 128
set chassis fpc 0 port-mirror-instance employee-monitor
Copy and paste the following commands in the destination switching device's terminal
window:
EX Series
[edit]
set vlans remote-analyzer vlan-id 999
set interfaces ge-0/0/10 unit 0 family ethernet-switching interface-mode access
set interfaces ge-0/0/10 unit 0 family ethernet-switching vlan members 999
set interfaces ge-0/0/5 unit 0 family ethernet-switching interface-mode access
set forwarding-options analyzer employee-monitor input ingress vlan remote-analyzer
set forwarding-options analyzer employee-monitor output interface ge-0/0/5.0
To configure basic remote mirroring:
On the source switching device, do the following:
1.
Configure the VLAN ID for the
[edit]
user@device# set vlans remote-analyzer vlan-id 999
Configure the interface on the network port connected to the destination switching
device for access mode and associate it with the
[edit]
user@device# set interfaces ge-0/0/10 unit 0 family ethernet-switching
interface-mode access
user@device# set interfaces ge-0/0/10 unit 0 family ethernet-switching vlan
members 999
Configure the statistical analyzer
[edit forwarding-options]
user@device# set analyzer employee-monitor input ingress interface ge-0/0/0.0
user@device# set analyzer employee-monitor input ingress interface ge-0/0/1.0
user@device# set analyzer employee-monitor input egress interface ge-0/0/0.0
user@device# set analyzer employee-monitor input egress interface ge-0/0/1.0
user@device# set analyzer employee-monitor output vlan remote-analyzer
user@device# set analyzer employee-monitor input rate 2
VLAN.
remote-analyzer
remote-analyzer
employee-monitor .
