Port Mirroring Analyzers Feature Guide for EX9200 Switches
Step-by-Step
Procedure
38
set forwarding-options analyzer employee-monitor input ingress bridge-domain
remote-analyzer
set forwarding-options analyzer employee-monitor output interface ge-0/0/5.0
To configure basic remote mirroring using MX Series routers:
On the source switching device, do the following:
1.
Configure the VLAN ID for the
[edit]
user@device# set bridge-domains remote-analyzer vlan-id 999
Configure the interface on the network port connected to the destination switching
device for access mode and associate it with the
[edit]
user@device# set interfaces ge-0/0/10 unit 0 family bridge interface-mode access
user@device# set interfaces ge-0/0/10 unit 0 family bridge vlan members 999
Configure the statistical analyzer
[edit forwarding-options]
user@device# set analyzer employee-monitor input ingress interface ge-0/0/0.0
user@device# set analyzer employee-monitor input ingress interface ge-0/0/1.0
user@device# set analyzer employee-monitor input egress interface ge-0/0/0.0
user@device# set analyzer employee-monitor input egress interface ge-0/0/1.0
user@device# set analyzer employee-monitor output bridge-domain
remote-analyzer
user@device# set analyzer employee-monitor input rate 2
user@device# set analyzer employee-monitor input maximum-packet-length 128
Bind the statistical analyzer to the FPC that contains the input interface.
[edit]
user@device# set chassis fpc 0 port-mirror-instance employee-monitor
On the destination switching device, do the following:
2.
Configure the VLAN ID for the
[edit bridge-domains]
user@device# set remote-analyzer vlan-id 999
Configure the interface on the destination switching device for access mode and
associate it with the
[edit interfaces]
user@device# set ge-0/0/10 unit 0 family bridge interface-mode access
user@device# set ge-0/0/10 unit 0 family bridge vlan members 999
Configure the interface connected to the destination switching device for access
mode.
[edit interfaces]
user@device# set ge-0/0/5 unit 0 family bridge interface-mode access
Configure the
employee-monitor
remote-analyzer
employee-monitor
remote-analyzer
bridge domain.
remote-analyzer
analyzer.
bridge domain.
bridge domain.
remote-analyzer
.
bridge domain.
