Analog Inputs:
Number of analog inputs
Terminal number
Voltage mode (Terminal 53)
Current mode (Terminal 53 and 60)
Voltage level
Input resistance, R
i
Max. voltage
Current level
Input resistance, R
i
Max. current
Analog output:
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load to common at analog output
Max. voltage at analog output
Accuracy on analog output
Resolution on analog output
Control card, RS-485 serial communication:
Terminal number
Terminal number 61
Control card, 24 V DC output:
Terminal number
Max. load (M1 and M2)
Max. load (M3)
Max. load (M4 and M5)
Relay output:
Programmable relay output
Relay 01 Terminal number
1)
Max. terminal load (AC-1) on 01-02 (NO) (Resistive load)
1)
Max. terminal load (AC-15) on 01-02 (NO) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 01-02 (NO) (Resistive load)
Max. terminal load (DC-13) 1) on 01-02 (NO) (Inductive load)
1)
Max. terminal load (AC-1) on 01-03 (NC) (Resistive load)
1)
Max. terminal load (AC-15) on 01-03 (NC) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 01-03 (NC) (Resistive load)
Min. terminal load on 01-03 (NC), 01-02 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5
Control card, 10 V DC output:
Terminal number
Output voltage
Max. load
NOTE
All inputs, outputs, circuits, DC supplies and relay contacts
are galvanically isolated from the supply voltage (PELV)
and other high-voltage terminals.
VLT Micro Drive Quick Guide
®
MG.02.B6.02 - VLT is a registered Danfoss trademark
Switch S200=OFF(U)
Switch S200=ON(I)
approx. 10 kΩ
0/4 to 20 mA (scaleable)
Max. error: 0.8 % of full scale
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
01-03 (break), 01-02(make)
250V AC, 0.2 A
250V AC, 0.2A
24V DC 10 mA, 24V AC 20 mA
overvoltage category III/pollution degree 2
1 1
2
53, 60
0 -10V
20V
approx. 200Ω
30mA
1
42
0/4 - 20mA
500Ω
17V
8bit
12
160mA
30mA
200mA
1
250V AC, 2 A
30V DC, 2 A
24V DC, 0.1A
250V AC, 2 A
30V DC, 2 A
50
10.5V ±0.5V
25mA
