GENERGY 2013022 Instructions For Use Manual page 92

Model
Regulation – Voltage – Frequency
Maximum AC
Nominal AC
Engine model
Displacement
Engine type
Sound level to 7m
Max. pressure guaranteed CE-LwA pursuant to
2000/14/EC
Startup type
Fuel tank capacity
Consumption/Running hours - Autonomy at 25% 50%
75% loads
Oil capacity – Type of oil
Transportation kit
Dimensions without / with wheels L x W x H (cm)
Machine weight / gross packaging (Kg)
Reference
Noise level measurements:
 The noise level at 7 m is the average sound level (lpA) obtained in four
directions and 7 meters from the generator.
NOTE: The level noise may change noticeably in different environments.
Equipment regulation compliance:
 Tested in accordance to EN12601:2010: safety in generators powered by
combustion engine
 In accordance to guidelines 2006/42/EC Machinery safety
 In accordance to guidelines 2006/95EC
 In accordance to guidelines 2004/108/EC Electromagnetic compatibility
 In accordance to 2000/14/EC (guideline 2005/88/EC) Sound emissions of the
exterior equipment on stage II June 2006.
GUARDIAN SC-6
Auto voltage regulator – 230V – 50Hz
6500w
6000w
SGH series 15HP
420cc
4-stroke OHV, air forced cooling.
74dB (A)
97dB
Manual/electric/ Autostart by signal contacts
28L
(1.6 l/h – 17.5h) (1.9 l/h – 14.7h) (2.5 l/h – 11.2h)
1.1L SAE10W30 - SAE10W40
Yes, with 10" rubber tires and metallic wheel.
70 x 53 x 59 / 75 x 67 x 68
96/99
2013025
Low voltage
44
