Configuring Fibre Channel Interfaces
DETAILED STEPS
Command or Action
Step 1
switch# configuration terminal
Step 2
switch(config)# feature npiv
Step 3 switch(config)# no npiv enable

Example Port Channel Configurations

This section shows examples on how to configure an F port channel in shared mode and how to bring up the
link between F ports on the NPIV core switches and NP ports on the NPV switches. Before you configure the
F port channel, ensure that F port trunking, F port channeling, and NPIV are enabled.
This example shows how to create the port channel:
switch(config)# interface port-channel 2
switch(config-if)# switchport mode F
switch(config-if)# switchport
switch(config-if)# channel mode active
switch(config-if)# exit
This example shows how to configure the port channel member interfaces on the core switch in dedicated
mode:
switch(config)# interface fc1/4-6
switch(config-if)# shut
switch(config-if)# switchport mode F
switch(config-if)# switchport speed 4000
switch(config-if)# switchport rate-mode dedicated
switch(config-if)# switchport trunk mode on
switch(config-if)# channel-group 2
switch(config-if)# no shut
switch(config-if)# exit
This example shows how to create the port channel in dedicated mode on the NPV switch:
switch(config)# interface san-port-channel 2
switch(config-if)# switchport mode NP
switch(config-if)# no shut
switch(config-if)# exit
This example shows how to configure the port channel member interfaces on the NPV switch:
switch(config)# interface fc2/1-2
switch(config-if)# shut
switch(config-if)# switchport mode NP
switch(config-if)# switchport trunk mode on
switch(config-if)# channel-group 2
switch(config-if)# no shut
switch(config-if)# exit
