User Guide
10ft Inground Trampoline
Got a Problem building your trampoline?
Call us on 0344 800 4060 and we can help
Patent no: DE602006006495D1, EP1721640B1 and US7628731
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
Advertisement
Table of Contents
Related Manuals for Jumpking 10ft Inground Trampoline
Summary of Contents for Jumpking 10ft Inground Trampoline
- Page 1 User Guide 10ft Inground Trampoline Got a Problem building your trampoline? Call us on 0344 800 4060 and we can help Patent no: DE602006006495D1, EP1721640B1 and US7628731 WARNING: Read these assembly instructions carefully before attempting to assemble or use this product. Keep...
- Page 2 ADVISORY . This trampoline is not intended to be buried in the ground. . The following product dimension relate to this 10ft Inground trampoline: Height from ground to top rail: 30cm (0.30m) Height from ground to top of enclosure: 222cm (2.22m) Height from top rail to top of enclosure: 192cm (1.92m)
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS surface. 1 user allowed at any one time. This can result in serious injury to head, neck, arms or legs. JUMPING INSTRUCTIONS Fundamental Bounce Knee Drop Hand and Knee Drop Start from a standing position with Start bouncing from a standing Start bouncing from a standing your head erect and your eyes on the position, keeping your eyes on the... -
Page 4: Care And Maintenance
CARE & MAINTENANCE Regular care and maintenance of your trampoline is required. This will help prolong its life and reduce the possibility of injury. Neglecting this can lead to a risk for users. Inspect your trampoline before each use using the checklist below as a guide. Take particular care in doing this at the start of each season and at regular intervals. -
Page 7: What You Will Need
BUILDING YOUR TRAMPOLINE 1. This is a 2 person build. 2. Time for build is approximately 2 hours. 3. Choose a good location: (wood chippings, sand or grass). (7.3m) from ground level, away from wires, trees and other possible hazards. (2.5m) around sides, away from walls, fences, structures, tarmac and other hard surfaces and play areas. -
Page 8: Parts List
PARTS LIST Part Part Part Part Description: Description: Description: Description: Top Tube with Top Tube without POD-connector T-connector Spring holes Spring holes Quantity: 5 Quantity: 10 Quantity: 10 Quantity: 10 Part Part Part Part Description: Description: Description: Description: Springs Stitched bed Spring tool Frame pad Quantity: 80... - Page 9 STEP 1 : ASSEMBLING THE FRAME POD-connector You will need the following parts to complete op tube with spring holes section 1: 10 x Top tube with spring holes - Part A T-connector 10 x Top tube without spring holes - Part B Top tube without spring holes 5 x POD-connector - Part C 5 x T-connector - Part D...
- Page 10 STEP 2 : ASSEMBLING THE FRAME This step will require 2 people who must be wearing gloves. Connect the top and bottom top tube together as shown in the diagram. POD-connector T-connector Important: Ensure all of the top tubes and connectors are fully inserted.
- Page 11 STEP 3 : FITTING THE STITCHED BED This step will require 2 people who must be wearing gloves and protective eye wear. Lay the stitched bed (with the V-Rings the frame of the trampoline with the warning labels facing upwards. Colored stitching Locate the 4 V-Rings with the colored stitching.
- Page 12 Attach the other two colored stitched V-Rings to the POD-connector using the same method as shown. Continue to attach springs in the same sequence as above: in the middle of each section, making sure the next spring is attached on the opposite side to even out the tension.
- Page 13 STEP 4 : FITTING THE FRAME PAD This step will require 2 people. Lay the frame pad - Part H out over the edge of the frame with the ties facing downwards. Align the openings in the frame pad with the POD-connector's on the frame.
- Page 14 STEP 5 : FITTING THE ENCLOSURE TUBES Top enclosure tube You will need the following parts to complete step 5: 6 x Top enclosure tubes - Part K Bottom enclosure tube 6 x Bottom enclosure tubes - Part J 6 x Self tapping screws and washers - Part I Self tapping screw and washer You will also need a cross-head screwdriver (not supplied).
- Page 15 Slot the bottom enclosure tube into the tubes in the POD-connector tubes visible through the slots in the frame pad. Assemble the remaining enclosure tubes using the self tapping screws and the cross-head screwdriver. Slot the remaining enclosure tubes into the 4 remaining POD-connector's on the frame.
- Page 16 STEP 6 : FITTING THE ENCLOSURE NETTING You will need the following parts to complete step 6: 2 x Black G3 poles - Part L Black G3 poles 1 x Enclosure netting - Part M Enclosure netting Lay the enclosure netting out on the trampoline. Find the sleeves that run along the top of the enclosure netting.
- Page 17 Slot one of the Black G3 poles through three of the sleeves on the top of the enclosure netting. Slot the remaining Black G3 poles through the three other sleeves on the top of the enclosure netting. You will now join the two ends of the Black G3 will require two people.
- Page 18 You may need to slide the connected poles around in the nettings sleeves until the thin black sections are aligned with the gaps between sleeves. Stand on the trampoline and insert one of the exposed sections of the Black G3 pole into a plastic grip on top of one of the enclosure tubes.
- Page 19 STEP 7 : ATTACHING THE BOTTOM OF THE NET You will need the following parts to complete step 7: 8 x Cords - Part N. Tie the non-plastic end of the cord around a V-Ring. Push the red plastic end through a hole in the bottom of the netting.
- Page 20 USING THE TRAMPOLINE Before using your trampoline, check again that there is enough clearance around it. Maintain a clear space of 2.5 metres (8.2 feet) on all sides of 2.5m the trampoline. 8.2ft Also check that the area is free from walls, structures, fences, tarmac and other hard surfaces and other play areas.
-
Page 21: Spare Parts
Jumping mat Foam sleeve cover Springs G3 FRP Enclosure mesh User manual Frame pad Cords Self tapping screw + Wahsers For a full range of accessories and replacement parts call 0344 800 4060 or visit our web site at: www.jumpking.eu...
