User Guide
14ft Inground Trampoline
Got a Problem building your trampoline?
Call us on 0344 800 4060 and we can help
Patent no: DE602006006495D1, EP1721640B1 and US7628731
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
Advertisement
Table of Contents
Related Manuals for Jumpking 14ft Inground Trampoline
Summary of Contents for Jumpking 14ft Inground Trampoline
- Page 1 User Guide 14ft Inground Trampoline Got a Problem building your trampoline? Call us on 0344 800 4060 and we can help Patent no: DE602006006495D1, EP1721640B1 and US7628731 WARNING: Read these assembly instructions carefully before attempting to assemble or use this product. Keep...
- Page 2 IMPORTANT INFORMATION . WARNING! ADULT SUPERVISION & GUIDANCE REQUIRED AT ALL TIMES. . Recommended age 6+ years. WARNINGS! . Only for domestic use. . Maximum user weight limit 120 kg. . Not suitable for children under 36 months - small parts, choking hazard. .
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS surface. 1 user allowed at any one time. This can result in serious injury to head, neck, arms or legs. JUMPING INSTRUCTIONS Fundamental Bounce Knee Drop Hand and Knee Drop Start from a standing position with Start bouncing from a standing Start bouncing from a standing your head erect and your eyes on the position, keeping your eyes on the... -
Page 4: Care And Maintenance
CARE & MAINTENANCE Regular care and maintenance of your trampoline is required. This will help prolong its life and reduce the possibility of injury. Neglecting this can lead to a risk for users. Inspect your trampoline before each use using the checklist below as a guide. Take particular care in doing this at the start of each season and at regular intervals. -
Page 7: What You Will Need
BUILDING YOUR TRAMPOLINE 1. This is a 2 person build. 2. Time for build is approximately 2 hours. 3. Choose a good location: (wood chippings, sand or grass). (7.3m) from ground level, away from wires, trees and other possible hazards. (2.5m) around sides, away from walls, fences, structures, tarmac and other hard surfaces and play areas. -
Page 8: Parts List
PARTS LIST Part Part Part Part Description: Description: Description: Description: Top Tube with Top Tube without POD-connector T-connector Spring holes Spring holes Quantity: 5 Quantity: 10 Quantity: 10 Quantity: 10 Part Part Part Part Description: Description: Description: Description: Springs Gold Springs Stitched bed Spring tool Quantity: 100... -
Page 9: Step 1 : Assembling The Frame
STEP 1 : ASSEMBLING THE FRAME POD-connector You will need the following parts to complete op tube with spring holes section 1: 10 x Top tube with spring holes - Part A T-connector 10 x Top tube without spring holes - Part B Top tube without spring holes 5 x POD-connector - Part C 5 x T-connector - Part D... - Page 10 STEP 2 : ASSEMBLING THE FRAME This step will require 2 people who must be wearing gloves. Connect the top and bottom top tube together as shown in the diagram. POD-connector T-connector Important: Ensure all of the top tubes and connectors are fully inserted.
- Page 11 STEP 3 : FITTING THE STITCHED BED This step will require 2 people who must be wearing gloves and protective eye wear. Lay the stitched bed (with the V-Rings the frame of the trampoline with the warning labels facing upwards. Colored stitching Locate the 4 V-Rings with the colored stitching.
- Page 12 Attach the other two colored stitched V-Rings to the POD-connector using the same method as shown. Continue to attach springs in the same sequence as above: in the middle of each section, making sure the next spring is attached on the opposite side to even out the tension.
- Page 13 STEP 4 : FITTING THE FRAME PAD This step will require 2 people. Lay the frame pad - Part H out over the edge of the frame with the ties facing downwards. Align the openings in the frame pad with the POD-connector's on the frame.
- Page 14 USING THE TRAMPOLINE Before using your trampoline, check again that there is enough clearance around it. Maintain a clear space of 2.5 metres (8.2 feet) on all sides of 2.5m the trampoline. 8.2ft Also check that the area is free from walls, structures, fences, tarmac and other hard surfaces and other play areas.
-
Page 15: Spare Parts
Self tapping screw + Wahsers Top tube without spring holes Spring pulling tool POD-connector User manual T-connector Jumping mat Springs Gold Springs For a full range of accessories and replacement parts call 0344 800 4060 or visit our web site at: www.jumpking.eu...
