Network Camera

Quick Start Guide

Thank you for purchasing this product. Please read this guide
carefully before operating the unit and retain it for future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the o2vld5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Speco o2vld5

  • Page 1: Network Camera

    Network Camera Quick Start Guide Thank you for purchasing this product. Please read this guide carefully before operating the unit and retain it for future reference.
  • Page 2 Warning and Caution ■ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. Any unauthorized changes or modifications could void the warranty. ■ Do not allow water or liquid intrusion into the camera. ■...
  • Page 3 Camera Quick start guide 4 tapping screws PA 4×35 Water proof cap ×4 Plastic plug Rubber plug Drill template Screwdriver Overview Mounting Base Mic in connector DC power connector Ethernet connector...
  • Page 4 DC12V * 1 It is recommended to install the water-proof cap for outdoor installations. * 2 DC 12V power supply is not required if a PoE switch or injector is used to power the camera. ► Connecting Network Cable ① Loosen the nut from the main element. ②...
  • Page 5 Installation Please make sure that the wall or ceiling is strong enough to withstand 3 times the weight of the camera. Please install and use the camera in a dry environment. ① Drill the screw holes and the cable hole on the wall according to the drill template.
  • Page 6 Rubber Plug ⑤ Three-axis adjustment. Before adjustment, preview the image of the camera on a monitor and then adjust the camera according to the figure below to get an optimum angle. Pan 0°~240° Tilt 0°~68° Rotation 0°~220° ⑥ Install the lower dome back to the camera and secure it with the screws.
  • Page 7 Web Operation IP Scanner can search for the device on the local network. ● Operation ① Make sure that the camera and the PC are connected to the same local network. The camera is set to DHCP by default. ② Install IP Scanner from the CD and run it after installation. ③...
  • Page 8 The login interface is shown above. Default user name is admin and password is 1234. After logging in, follow directions to install applicable plugins. 450043000576 A0...
