Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the device will respond to the controller.
If you set, for example, the address in the 10 channel mode to channel 11, the device will use the channel 11
to 20 for control.
Please, be sure that you don't have any overlapping channels in order to control each device correctly and
independently from any other fixture on the DMX-chain.
If several devices are addressed similarly, they will work synchronically.
For setting the desired starting address please press the MENU button until the display shows DMX
Address. Press the ENTER button and the display shows: 001. Set the desired address via the UP or
DOWN buttons. Please press the ENTER button again to confirm.
Now you can start operating the device via your lighting controller.
Note:
The modes of DMX512 data are shown via the display of the device:
After switching on, the device will automatically detect whether DMX 512 data is received or not. If the data
is received, the display will show
show one of the following symbols:
This situation can occur if:
- the wireless receiver is not logged in to the wireless transmitter or no wireless DMX signal is received.
- the controller is switched off or defective
- WDMX is de-activated.

DMX Protocol

Mode/Channel
10
4 Ch 6 Ch HSV HSI
Ch
1
2
3
1 1 2
2 2 3
3 3 4
4 4 5
5 1
. If there is no data received at the DMX-input, the display will
Decimal Hexad.
1
0 255 00 FF
2
0 255 00 FF
0 255 00 FF
3
0 255 00 FF
0 255 00 FF
0 255 00 FF
0 255 00 FF
0 255 00 FF
.
Percentage S/F
Hue
0% 100% F Hue selection
Saturation
0% 100% F 0 - 100 % increasing
Value (brightness)
0% 100% F 0 - 100 % increasing
Intensity
0% 100% F 0 - 100 % increasing
Red
0% 100% F Red 0 - 100 % increasing
Green
0% 100% F Green 0 - 100 % increasing
Blue
0% 100% F Blue 0 - 100 % increasing
White
0% 100% F White 0 - 100 % increasing
Dimmer intensity
35/40
Feature
00106659, Version 1.0
