EuroLite AKKU IP UP-4 QCL SPOT User Manual page 36

6 6
7
8
9
10
0 255 00 FF 0%
0 10 00 0A 0%
11 255 0B FF 4%
0 10 00 0A 0%
11 30 0B 1E 4%
31 50 1F 32 12%
51 70 33 46 20%
71 90 47 5A 28%
91 110 5B 6E 36%
111 130 6F 82 44%
131 150 83 96 51%
151 170 97 AA 59%
171 200 AB C8 67%
201 205 C9 CD 79%
206 210 CE D2 81%
211 215 D3 D7 83%
216 220 D8 DC 85%
221 225 DD E1 87%
226 230 E2 E6 89%
231 235 E7 EB 91%
236 240 EC F0 93%
241 245 F1 F5 95%
246 250 F6 FA 96%
251 255 FB FF 98% 100%
0 51 00 33 0%
52 101 34 65 20%
102 152 66 98 40%
153 203 99 CB 60%
204 254 CC FE 80% 100%
255 255 FF FF 100% 100%
0 255 00 FF 0%
0 51 00 33 0%
52 101 34 65 20%
102 152 66 98 40%
153 203 99 CB 60%
204 255 CC FF 80% 100%
36/40
Gradual adjustment of the dimmer
100% F intensity from 0 to 100 %
Strobe
4% S No function
100% F Strobe-effect with increasing speed
Color presets
4%
S No function
12% F
Red 100% / green increasing / blue 0%
20% F
Red decreasing / green 100% / blue 0%
27% F
Red 0% / green 100% / blue increasing
35% F
Red 0% / green decreasing / blue 100%
43% F
Red increasing / green 0% / blue 100%
51% F
Red 100% / green 0% / blue decreasing
Red 100% / green increasing / blue
59% F
increasing
Red decreasing / green decreasing /
67% F
blue 100%
Red 100% / green 100% / blue 100% /
78% F
white 100%
80% S
WHITE color temperature 1
82% S
WHITE color temperature 2
84% S
WHITE color temperature 3
86% S
WHITE color temperature 4
88% S
WHITE color temperature 5
90% S
WHITE color temperature 6
92% S
WHITE color temperature 7
94% S
WHITE color temperature 8
96% S
WHITE color temperature 9
98% S
WHITE color temperature 10
S
WHITE color temperature 11
Internal programs
20% S
No function
40% S Internal program 1
60% S Internal program 2
80% S Internal program 3
S Internal program 4
S Internal program 5
Speed internal programs
100% F
Increasing speed
Dimmer speed (step response)
20% S
Control Board setting dimmer speed
40% S OFF
60% S
Dimmer speed 1
80% S
Dimmer speed 2
S
Dimmer speed 3
warm
cold
00106659, Version 1.0
