Technical Specifications - EuroLite AKKU IP UP-4 QCL SPOT User Manual

TECHNICAL SPECIFICATIONS

Power supply (case):
Power consumption during charging process:
Power supply (LED uplight):
Battery pack type:
Battery operation:
Recharging time:
Protection grade (LED uplight):
Battery remote control:
DMX control channels:
Wireless signal transmission:
LED type:
Number of LEDs:
Beam angle:
Dimensions LED uplight (LxWxH):
Weight LED uplight:
Dimensions Case (LxWxH):
Weight total:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
Accessory:
FUTURELIGHT WDS-G4 TX wireless DMX transceiver
EUROLITE IR-7 Remote control
EUROLITE TPC-10 Coupler, silver
EUROLITE Safety bond A 3x600mm up to 5kg, silver
:
a
:
C
38/40
100-240 V AC, 50/60 Hz ~
330 W
24 V DC
Li-ion 14.8 V, 11000 mAh (162.8 Wh)
depending on program used up to 17 hours
5 hours
IP 54
CR2025 button cell 3 V
HSV/HSI/4/6/10
2.4 GHz (ISM)
10 W QCL
4 (each LED uplight)
9°
145 x 138 x 202 mm
3.8 kg
537 x 470 x 540 mm
46 kg
45° C
55° C
0.5 m
0.1 m
T 5 A, 250V
No. 51834022
No. 50530561
No. 59006856
No. 58010310
00106659, Version 1.0
