- Page 1 Installation, Operation & Maintenance Model: PBE12 & PBE24 Star Manufacturing International 10 Sunnen Drive St. Louis, MO 63143 Part Number: 2M-Z9993 Phone: (314) 781-2777, Fax: (314) 781-2714 Rev. C WWW.STAR-MFG.COM October 23, 2007...
- Page 2 SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability.
-
Page 3: Table Of Contents
READ FIRST......................4 EQUIPMENT DESCRIPTION ................6 UNPACKING.....................7 INSTALLATION ....................8 INITIAL START UP ..................10 OPERATION......................11 CLEANING & MAINTENANCE PROCEDURES ..........13 WIRING DIAGRAM PBE12 ................14 WIRING DIAGRAM PBE24 ................15 PBE12 EXPLODED VIEW & PARTS LIST.............16-17 PBE24 EXPLODED VIEW & PARTS LIST.............18-19 Rev. - 2006... -
Page 4: Read First
IMPORTANT READ FIRST IMPORTANT CAUTION: THE GRIDDLE PBE12 WEIGHS 70 LBS (32 KG). THE PBE24 WEIGHS 130 LBS (59 KG). FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED OR EMPLOY APPROPRIATE MATERIALS- HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY OR PALLET JACK) TO REMOVE THE UNIT FROM THE PACKAGING AND MOVE IT TO THE PLACE OF INSTALLATION. - Page 5 IMPORTANT READ FIRST IMPORTANT WARNING: KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND PROTECTIVE CLOTHING.
-
Page 6: Equipment Description
EQUIPMENT DESCRIPTION Pane Bella, Single Grill (PBE12) • Power: The PBE12 operates on 120, 208 or 240 volts. Each grill is supplied with the appropriate cord and plug built in. • Counter space required: 13.3 in wide (33.7 cm) and 14.0 in deep (35.6 cm). -
Page 7: Unpacking
15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. -
Page 8: Installation
The electrical service entrance is provided by a cord and plug located at the rear of the appliance. The plug provided for 208/240V is a L6-30P. The PBE12 120V comes with a standard plug. The receptacle for a 208/240V is a L6-30R and must be supplied by the installer. - Page 9 INSTALLATION CONT’D Ventilation and Clearances Standard minimum clearance from combustible construction is as follows: 1 inches from sides 4 inches from back 1 inches from floor The installation of any components such as a vent hood, grease extractors and/or fire extinguisher systems must conform to applicable nationally recognized installation standards.
-
Page 10: Initial Start Up
INITIAL START UP Initial Start Up Before starting the grill for the first time, clean the grill body and cooking surfaces with a mild soap and water solution, then rinse with clear water and dry. Close the upper cooking surface and set the temperature to 200°F (93°C) for two hours to evaporate any moisture that may be in the elements and grill castings. -
Page 11: Operation
OPERATION Control Panel TIME START / Display SET TEMP MODE DOWN RESET READY Time & Set Temp Lights Either light will illuminate to indicate which mode has been accessed (see Mode Button instructions). Ready Light This light will illuminate when the Actual Temp reaches the Set Temp. Display Time or Set Temp will be displayed, corresponding with the mode that has been selected (see Mode Button instructions). - Page 12 OPERATION CONT’D Setting the Temperature CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM COMBUSTIBLE MATERIALS. CAUTION: KEEP THE FLOOR IN FRONT OF THE EQUIPMENT CLEAN AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.
-
Page 13: Cleaning & Maintenance Procedures
1-800-807-9054 or www.star-mfg.com for the service agent nearest you. Lang Manufacturing has designed the Pane Bella to be easy to clean and maintain. We advise a daily cleaning schedule to keep your grill looking like new. After the “seasoning process” use any vegetable non-stick spray sparingly. -
Page 14: Wiring Diagram Pbe12
This drawing contains information confidential to Lang Manufacturing, No reproduction or disclosure of its contents is permitted. SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE MODEL: SK2222 REV. B 12/5/2007 PBE12... -
Page 15: Wiring Diagram Pbe24
PARTS LIST December 5, 2007, Rev. C PBE12 Pane Bella Electric Single, 120V-208/240V MODEL Number Part Number Number Description Unit 2N-11030-40 ELE GRDPANI208/240V900W PBE12G 2N-11030-51 ELE GRD PANI 110V 900W PBE12G-120V, PBE12S, S-120V 2N-11030-41 ELEGRDPANI208/240V720W PBE12G 2N-11030-52 ELE GRD PANI 110V 720W... -
Page 16: Pbe12 Exploded View & Parts List
This drawing contains information confidential to Lang Manufacturing, No reproduction or disclosure of its contents is permitted. SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE MODEL: SK2223 REV. A 10/23/2007 PBE24... - Page 17 PARTS LIST December 5, 2007, Rev. C PBE24 Pane Bella Electric Double 208/240V MODEL Number Part Number Number Description Unit 2N-11030-40 ELE GRDPANI208/240V900W PBE24G, PB, GS, S 2N-11030-41 ELEGRDPANI208/240V720W PBE24G, PB, GS, S 2E-30303-28 SWT ROCKER ON-OFF-ON PBE24G, PB, GS, S 2T-30401-31 STAT FXD 400 DEG OPEN PBE24G, PB, GS, S...
- Page 20 STAR MANUFACTURING 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
